Datasheet
500mA Variable / Fixed Output
LDO Regulators
BDxxGA5WEFJ
●General
Description
BDxxGA5WEFJ series devices are LDO regulators with an output current of 0.5A. The output accuracy is ±1% of the output
voltage. Both fixed and variable output voltage devices are available. The output voltage of the variable output voltage
device can be varied from 1.5 to 13.0V using external resistors. Various fixed output voltage devices that do not use
external resistors are also available. It can be used for a wide range of digital appliance applications. It has a small package
type: HTSOP-J8 (4.90mm x 6.00mm x 1.00mm). These devices have built in over current protection to protect the device
when output is shorted, 0µA shutdown mode and thermal shutdown circuit to protect the device during over load conditions.
These LDO regulators are usable with ceramic capacitors that enable a smaller layout and longer life.
●Features
+/-1% output voltage accuracy
Built-in Over Current Protection circuit (OCP)
Built-in Thermal Shut Down circuit (TSD)
Zero µA shutdown mode
●Key
Specification
Input Power Supply Voltage range:
4.5V to 14.0V
Output voltage range(Variable type):
1.5V to 13.0V
Output voltage(Fixed type): 1.5V/1.8V/2.5V/3.0V/3.3V
5.0V/6.0V/7.0V/8.0V/9.0V/10V/12V
Output current:
0.5A(Max.)
Shutdown current:
0μA(Typ.)
Operating temperature range:
-25℃ to +85℃
HTSOP-J8
●Package
HTSOP-J8
(Typ.)
(Typ.)
(Max.)
4.90mm x 6.00mm x 1.00mm
●Typical
Application Circuit
V
CC
C
IN
EN
GND
FIN
V
O
R
1
FB
R
2
C
OUT
C
IN
V
CC
V
O
V
O_S
C
OUT
EN
GND
FIN
C
IN
,C
OUT
: Ceramic Capacitor
C
IN
,C
OUT
: Ceramic Capacitor
Variable output voltage type
Fixed output voltage type
○Product
structure：Silicon monolithic integrated circuit
www.rohm.com
© 2013 ROHM Co., Ltd. All rights reserved.
TSZ22111½14½001
○This
product is not designed protection against radioactive rays.
1/19
TSZ02201-0R6R0A600190-1-2
7.Feb.2013 Rev.002
BDxxGA5WEFJ
●Ordering
Information
Datasheet
B
D
x
x
G
A
5
W
E
F
J
-
E2
Part
Output
Number voltage
Input
voltage
range
G:15V
Output
Current
Shutdown
mode
Package
Packaging and forming specification
00:Variable
15:1.5V
18:1.8V
25:2.5V
30:3.0V
33:3.3V
50:5.0V
60:6.0V
70:7.0V
80:8.0V
90:9.0V
J0:10.0V
J2:12.0V
A5:0.5A “W”:included EFJ:HTSOP-J8
E2:Emboss tape reel
www.rohm.com
© 2013 ROHM Co., Ltd. All rights reserved.
TSZ22111½15½001
2/19
TSZ02201-0R6R0A600190-1-2
7.Feb.2013 Rev.002
BDxxGA5WEFJ
●Block
Diagram
BD00GA5WEFJ(Variable output voltage type)
Datasheet
V
CC
SOFT
START
V
O
Fig.1 Block Diagram
●Pin
Configuration
TOP VIEW
V
O
FB
GND
N.C.
V
CC
N.C.
N.C.
EN
●Pin
Description
Pin No.
Pin name
1
V
O
2
FB
3
GND
4
N.C.
5
EN
6
N.C.
7
N.C.
8
V
CC
Reverse
FIN
Pin Function
Output pin
Feedback pin
GND pin
No Connect (Connect to GND or leave OPEN)
Enable pin
No Connect (Connect to GND or leave OPEN)
No Connect (Connect to GND or leave OPEN)
Input pin
Substrate(Connect to GND)
www.rohm.com
© 2013 ROHM Co., Ltd. All rights reserved.
TSZ22111½15½001
3/19
TSZ02201-0R6R0A600190-1-2
7.Feb.2013 Rev.002
BDxxGA5WEFJ
●Block
Diagram
BDxxGA5WEFJ(Fixed output voltage type)
Datasheet
V
CC
OCP
SOFT
START
V
O
EN
TSD
V
O_S
GND
Fig.2 Block Diagram
●Pin
Configuration
TOP VIEW
V
O
V
O_S
GND
N.C.
V
CC
N.C.
N.C.
EN
●Pin
Description
Pin No.
1
2
3
4
5
6
7
8
Reverse
Pin name
V
O
V
O_S
GND
N.C.
EN
N.C.
N.C.
V
CC
FIN
Pin Function
Output pin
Output voltage monitor pin
GND pin
No Connect (Connect to GND or leave OPEN)
Enable pin
No Connect (Connect to GND or leave OPEN)
No Connect (Connect to GND or leave OPEN)
Input pin
Substrate(Connect to GND)
www.rohm.com
© 2013 ROHM Co., Ltd. All rights reserved.
TSZ22111½15½001
4/19
TSZ02201-0R6R0A600190-1-2
7.Feb.2013 Rev.002
BDxxGA5WEFJ
●Absolute
Maximum Ratings (Ta=25℃)
Parameter
Power supply voltage
EN voltage
Power dissipation
HTSOP-J8
Operating Temperature Range
Storage Temperature Range
Junction Temperature
Symbol
V
CC
V
EN
Pd
*2
Topr
Tstg
Tjmax
Ratings
15.0 *
1
15.0
2110
*2
-25 to +85
-55 to +150
+150
Unit
V
V
mW
℃
℃
℃
Datasheet
*1 Not to exceed Pd
*2 Reduced by 16.9mW/℃ for each increase in Ta of 1℃ over 25℃. (when mounted on a board 70mm×70mm×1.6mm glass-epoxy board, two layer)
●Recommended
Operating Ratings (Ta=25℃)
Parameter
Input power supply voltage
EN voltage
Output voltage setting range
Output current
Symbol
V
CC
V
EN
V
O
I
O
Ratings
Min.
4.5
0.0
1.5
0.0
Max.
14.0
14.0
13.0
0.5
Unit
V
V
V
A
●Electrical
Characteristics (Unless otherwise noted, Ta=25℃, EN=3V, V
CC
=6V, R
1
=43kΩ, R
2
=8.2kΩ)
Parameter
Circuit current at shutdown mode
Bias current
Line regulation
Load regulation
Minimum dropout voltage1
Minimum dropout voltage2
Minimum dropout voltage3
Minimum dropout voltage4
Output reference voltage(Variable type)
Output voltage(Fixed type)
EN Low voltage
EN High voltage
EN Bias current
Symbol
I
SD
I
CC
Reg.I
Reg I
O
V
CO1
V
CO2
V
CO3
V
CO4
V
FB
V
O
V
EN
(Low)
V
EN
(High)
I
EN
Min.
-
-
-1
-1.5
-
-
-
-
0.792
V
O
×0.99
0
2.4
1
Limits
Typ.
0
600
-
-
0.24
0.36
0.48
0.60
0.800
V
O
-
-
3
Max.
5
900
1
1.5
0.36
0.54
0.72
0.90
0.808
V
O
×1.01
0.8
14.0
9
Unit
µA
µA
%
%
V
V
V
V
V
V
V
V
µA
Conditions
V
EN
=0V, OFF mode
V
CC
=( V
O
+0.9V )→14.0V
I
O
=0→0.5A
V
CC
=5V, I
O
=200mA
V
CC
=5V, I
O
=300mA
V
CC
=5V, I
O
=400mA
V
CC
=5V, I
O
=500mA
I
O
=0A
I
O
=0A
www.rohm.com
© 2013 ROHM Co., Ltd. All rights reserved.
TSZ22111½15½001
5/19
TSZ02201-0R6R0A600190-1-2
7.Feb.2013 Rev.002
