AD8074_15 Overview

Video Buffers with Disable

Preview

Download Datasheet

View All

FEATURES

Dual Supply 5 V

High-Speed Fully Buffered Inputs and Outputs

600 MHz Bandwidth (–3 dB) 200 mV p-p

500 MHz Bandwidth (–3 dB) 2 V p-p

1600 V/ s Slew Rate, G = +1

1350 V/ s Slew Rate, G = +2

Fast Settling Time: 4 ns

Low Supply Current: <30 mA

Excellent Video Specifications (R

= 150 ):

Gain Flatness of 0.1 dB to 50 MHz

0.01% Differential Gain Error

0.01 Differential Phase Error

“All Hostile“ Crosstalk

–80 dB @ 10 MHz

–50 dB @ 100 MHz

High “OFF” Isolation of 90 dB @ 10 MHz

Low Cost

Fast Output Disable Feature

APPLICATIONS

RGB Buffer in LCD and Plasma Displays

RGB Driver

Video Routers

500 MHz, G = +1 and +2 Triple

Video Buffers with Disable

AD8074/AD8075

FUNCTIONAL BLOCK DIAGRAM

AD8074 /AD8075

DGND

IN2

AGND

IN1

AGND

IN0

+1/+2

OUT2

OUT1

OUT0

PRODUCT DESCRIPTION

Table I. Truth Table

The AD8074/AD8075 are high-speed triple video buffers with

G = +1 and +2 respectively. They have a –3 dB full signal band-

width in excess of 450 MHz, along with slew rates in excess of

1400 V/µs. With better than –80 dB of all hostile crosstalk and

90 dB isolation, they are useful in many high-speed applica-

tions. The differential gain and differential phase error are 0.01%

and 0.01°. Gain flatness of 0.1 dB up to 50 MHz makes the

AD8074/AD8075 ideal for RGB buffering or driving. They

consume less than 30 mA on a

5 V supply.

Both devices offer a high-speed disable feature that allows the

outputs to be put into a high impedance state. This allows the

building of larger input arrays while minimizing “OFF” chan-

nel output loading. The AD8074/AD8075 are offered in a

16-lead TSSOP package.

OUT0, 1, 2

IN0, IN1, IN2

High Z

Rev. B

Information furnished by Analog Devices is believed to be accurate and

reliable. However, no responsibility is assumed by Analog Devices for its

use, nor for any infringements of patents or other rights of third parties that

may result from its use. No license is granted by implication or otherwise

under any patent or patent rights of Analog Devices.

One Technology Way, P.O. Box 9106, Norwood, MA 02062-9106, U.S.A.

www.analog.com

Tel: 781.329.4700

Fax: 781.461.3113
