MSCD165
Glass Passivated Rectifier
Diode Modules
V
RRM
800 to 1800V
I
FAV
165 Amp
Applications
Non-controllable rectifiers for AC/AC
converters
Line rectifiers for transistorized AC motor
controllers
Field supply for DC motors
Circuit
Features
Blocking voltage:800 to 1800V
Heat transfer through aluminum oxide DBC
ceramic isolated metal baseplate
Glass passivated chip
UL E243882 approved
Module Type
TYPE
MSCD165-08
MSCD165-12
MSCD165-16
MSCD165-18
MSAD165-08
MSAD165-12
MSAD165-16
MSAD165-18
MSKD165-08
MSKD165-12
MSKD165-16
MSKD165-18
V
RRM
800V
1200V
1600V
1800V
V
RSM
900V
1300V
1700V
1900V
Maximum Ratings
Symbol
Conditions
Single phase ,half wave 180°conduction Tc=101℃
I
FAV
Single phase ,half wave 180°conduction Tc=101℃
I
F(RMS)
t=10mS Tvj =45℃
I
FSM
t=10mS Tvj =45℃
i
2
t
a.c.50HZ;r.m.s.;1min
V
isol
T
vj
T
stg
Mt
Ms
Weight
To terminals(M6)
To heatsink(M6)
Values
165
220
6000
180000
3000
-40 to +150
-40 to +125
5±15%
5±15%
160
Units
A
A
A
A
2
s
V
℃
℃
Nm
Nm
g
Module (Approximately)
Thermal Characteristics
Symbol
Per diode
R
th(j-c)
Module
R
th(c-s)
Electrical Characteristics
Symbol
V
FM
I
RD
T=25℃ I
F
=300A
Conditions
Values
0.21
0.05
Units
℃/W
℃/W
Conditions
T
vj
=150℃ V
RD
=V
RRM
1
Values
Min.
－
－
Typ.
1.20
－
Max.
1.40
9
Units
V
mA
Document Number: MSCD165
Aug.31, 2010
www.
smsemi.com
MSCD165
Performance Curves
300
W
DC
rec.120
rec.30
rec.60
sin.180
250
A
200
sin.180
DC
150
rec.120
150
rec.60
100
rec.30
50
P
vtot
0
0 I
D
120
A 240
I
D
0
0 Tc
50
100
℃
150
Fig1. Power dissipation
0.3
℃/
W
8000
A
Fig2.Forward Current Derating Curve
50HZ
Z
th(j-
C
)
0.15
4000
0
0.001
0.01
0.1
1.0
10
S 100
0
1
10
cycles 100
Fig3. Transient thermal impedance
400
A
300
Fig4. Max Non-Repetitive Forward Surge
Current
200
typ.
max.
100
I
F
0
0
V
F
0.5
1.0
1.5
V 2.0
25℃
- - -125℃
Fig5. Forward Characteristics
Document Number: MSCD165
Aug.31, 2010
www.
smsemi.com
2
