CFS28** Series –WIRE WOUND COMMON MODE FILTERS
A. Electrical Specifications:
Part
Number
CFS28**-01
CFS28**-02
CFS28**-03
CFS28**-04
CFS28**-05
CFS28**-06
CFS28**-07
CFS28**-08
CFS28**-09
CFS28**-10
Rev. A
Inductance Min.
(mH)
3.3
5.6
8.0
16
39
45
60
68
96
120
DCR Max.
(Ω)
0.12
0.16
0.16
0.40
0.65
0.80
1.00
1.50
2.00
2.50
Rated Current
(A)
3.0
2.5
2.0
1.5
1.0
0.9
0.8
0.7
0.6
0.5
Note: CFS28**-xx: “CFS28**” = P/N, “28”= Size, “**”= Type, “xx” = Dash number.
B. Dimensions: mm (Inch)
Series
CFS2801 Series
TYPE 01
Tol.
CFS2802 Series
TYPE 02
Tol.
a
22.0
(0.866)
Max.
29.5
(1.161)
Max.
b
10.0
(0.394)
±0.5
(0.020)
20.0
(0.787)
±0.5
(0.020)
c
31.0
(1.220)
Max.
29.5
(1.161)
Max.
d
35.5
(1.398)
Max.
24.5
(0.965)
Max.
e
5.0
(0.197)
Typ.
4.0
(0.157)
±1.0
(0.039)
f
13.0
(0.512)
±0.5
(0.020)
24.0
(0.945)
±0.5
(0.020)
g
Ø0.8
(0.031)
Typ.
Ø0.8
(0.031)
Typ.
h
13.0
(0.512)
Typ.
24.0
(0.945)
Typ.
i
10.0
(0.394)
Typ.
20.0
(0.787)
Typ.
TYPE 01
TYPE 02
C. General Information:
1.
2.
3.
4.
5.
P/N: CFS28**-xx, “CFS28**” = Size & Type, “xx” = Dash number.
Inductance measurement condition: 1.0 KHz, at 25°C.
Temperature Rise: 45°C Max.
Withstanding Voltage: 1500VAC for one minute between each winding.
MSL: Level 1.
D. Applications:
1.
2.
3.
4.
5.
6.
Game Consoles
Set Top Boxes
Cables Modems
Computers
Mobile Communication Devices (Radios, etc.)
LCD, DVD, BRP
Frontier Electronics Corp.
®
http://www.frontierusa.com
Page
1
of
1
667 E. Cochran St., Simi Valley, CA 93065
Phone: 1-805-522-9998, Fax: 1-805-522-9989
