SCREW MOUNTING
INTRODUCTIONS
1. Designed to meet globally accepted IEC publication 320 Class 1,
that allows users to comply with industry standard in power entry
requirement.
2. Connector for cold condition, with pin temperature 70
o
C max.
3. Nickel-plated brass pins and soldering terminals.
4. Screw-on mount from front or rear (with screw type-M3).
5. Fuse holder designed for one fuse and one spare fuse (both 5x20mm
fuses). Safety interlock prevents fuse removal with line plug inserted.
6. Adapts to 110V or 240V input voltage simply by reversing the voltage
selector.
7. All part numbers are UL recognized, CSA certified
except for SK-015A which is UL listed.
SK-1000 are DEMKO, approved.
SK-1017 is UL, CSA approved.
SK-1008 UL, CSA, VDE, CCC approved.
SK-1007A UL, CSA approved.
SK-1007A is patented for new construction (R.O.C. patent no. 54606).
SK-015A is UL, CSA, VDE, Somko, CCC. Approved
V
D E
SPECIFICATIONS
1. Rated voltage: 250VAC
2. Minimum insulation resistance at 500VDC: 10M OHM
3. Dielectric strength (one minute): 2000VAC between pins
4. Flammability class: UL 94V-0
ELECTRICAL SCHEMATIC
F
L
L
I
N
E
N
G
L
O
A
D
N
G
L
FIG. A
L
CUSTOMER TRANSFORMER PRIMARIES
L
L
I
N
E
F
L
O
A
D
N
120V
N
120V
FIG. B
POWER ENTRY MODULES
TYPE & RATED CURRENT
DELTA PART NUMBER
RATED CURRENT
(AT 250VAC)
CONNECTOR TYPE
FUSE HOLDER
VOLTAGE SELECTOR
ELECTRICAL SCHEMATIC
UL
CSA
VDE
SEMKO
CCC
UL/CSA
VDE
MALE
FEMALE
-
-
-
S *4
-
FIG. A
S *2
-
FIG. A
S *4
FRONT *3
FIG. B
SK-015A
15A
10A
SK-1000
15A
10A
SK-1017
15A
10A
SK-1007A
10A
10A
REMARKS:
1. SK-015A RATING
SEV/SEMKO/NEMKO/DEMKO_10A/250VAC
SK-1017/SK-1000
SEMKO/NEMKO/SETI/DEMKO_10A/250VAC
2. SK-1017 FUSE HOLDER
SINGLE FUSE HOLDER ON SK-1017
IS A RETAINED DESIGN
3. VOLTAGE SELECTOR CARD RA
TING
UL/CSA/VDE_10A/250VAC
4. "S" FOR SINGLE FUSE HOLDER
MECHANICAL CONSTRUCTION
1.97MAX.
50.0MAX.
1.575
40.0
1.19
30.3
THD. M3
0.14
3.5
+0.008
-
1.080
+0.2
-
27.50
R0.157MAX.(4X)
R4.0MAX.(4X)
0.88
22.3
1.575 0 .004
40.0 0 .1
R0.24(4X)
R6.0(4X)
0.12
3.0
MOUNTING CUTOUT
(FRONT MOUNTING)
1.12MAX.
28.5MAX.
0.13(2X)
3.3(2X)
0.79MAX.
20.0MAX.
1.08MAX.
27.5MAX.
SK-015A
+0.04
0.47-0.02
+1.0
12.0-0.5
0.12
3.0
+0.02
0.59-0
+0.5
15.0-0
+0
0.67-0.04
+0
17.0-1
+0.008
0.79-0
+0.2
20.0-0
UNIT:
INCH
mm
9-1
