NOTES: UNLESS OTHERWISE SPECIFIED
1. FOR GENERAL SERIES SPECIFICATIONS, SEE SD10-0000.
2. SEE CONTACT SALES DRAWING FOR CONTACT SPECIFICATIONS
2. MATERIAL SPECIFICATIONS:
SHELLS: COLD ROLLED STEEL PER ASTM A568
SIGNAL CONTACTS: BRASS PER ASTM B16
INSULATOR: GLASS FILLED
3. FINISH SPECIFICATIONS:
SHELLS: TIN PLATE PER ASTM B545
SIGNAL CONTACTS: .000030 IN. MIN Au PER ASTM B488 OVER
.000050 IN. MIN Ni PER SAE-AMS-QQ-N-290
INSULATOR: BLACK
4X 222-010-00420
2X PLUG
.470
FLANGE
REFERENCE
SHELL FLANGE
REFERENCE
11.94
.652
.437
16.56
11.10
REV
DESCRIPTION
BY
APPD
DATE
RDG
07/31/07
WPM
08/06/07
.978
.870
.761
24.84
22.10
A
EWR07-ER3606
19.33
4X
.144 3.66
.004[0.10] A
.040 1.02
.004[0.10] A
7X
.093
2.36
.100
2.54
.707
.815
17.96
20.70
23.47
9.09
22.56
A
.270 6.86
RECOMMENDED HOLE
PATTERN; SHOWN FROM
COMPONENT SIDE OF
PCB
.924
.358
2.728 69.29
2.500 63.50
2.182 55.42
.490 12.45
MAX
.232 5.89
C
L
.888
.492 12.50
.246 6.25
.329 8.36
DETAIL A
SCALE 2 : 1
A
.036 .91
13X .020 .51
MAX
2X
.120 3.05
7X .115 2.92
6X
7X
.024 .61
.125 3.18
CATALOG P/N: RM13W6P-1017
PER ASME Y14.5M-1994
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN INCHES [MM]
TOLERANCES:
DECIMAL: .XX [X.X] ± .01 [0.3]
.XXX [X.XX] ± .005 [0.13]
.XXXX [X.XXX] ± .XXXX
ANGLES: ± 2°
SCALE: 1:1
W
inches
er
E
lec
ronics
Winchester Electronics Corporation
62 Barnes Industrial Road North
Wallingford, Connecticut 06492
CUSTOMER
DRAWING
DRAWN
RDG
APPROVED
JC
DATE APPROVED
07/31/07 WPM
DATE APPROVED
08/06/07
MA
DATE
08/06/07
DATE
08/06/07
D-SUB PLUG CONNECTOR
A
SDRM13W6P-1017
SHT
1
OF
1
REV
A
