Two jacketed layers and two steel tape armor layers
Provide superior rodent resistance for direct-buried ap-
plications
Flexible, craft-friendly buffer tubes
Facilitate easy routing in closures
Cable core features innovative waterblocking tech-
nology
Eliminates the need for traditional flooding compound
and provides efficient and craft-friendly cable preparation
Medium-density polyethylene jacket
Makes cable rugged and durable while being flexible and
easy to strip
ALTOS
®
Lite™ double-jacket, double-armored cables are
rugged cables designed for direct-buried installations.
The loose tube design provides stable performance over
a wide temperature range and is compatible with any
telecommunications-grade optical fiber.
Standards
Design and Test Criteria
ANSI/ICEA S-87-640
Telcordia GR-20
RDUP PE-90
Corrugated Steel
Armor
Corrugated Steel Armor
Polyethylene (PE)
Inner Jacket
Dielectric Central
Element
Fiber
Ripcord
Buffer
Tube
Water-Swellable
Tape
Water-Swellable
Tape
Polyethylene (PE)
Outer Jacket
ALTOS Lite Double-Jacket, Double-Armored
Cables, 72 Fibers, Enhanced
| Photo PIM1333
Family Spec Sheet 0092_NAFTA_AEN
Page 1 | Revision date 2014-08-08
ALTOS Lite Double-Jacket, Double-Armored
Cables, 72 Fibers, Enhanced
| Photo PIM2231
ALTOS
®
Lite™ Double-Jacket, Double-
Armored Cables, 12-216 Fibers, Enhanced
Corrugated Steel
Armor
Corrugated Steel Armor
Polyethylene (PE)
Inner Jacket
Dielectric Central
Element
Fiber
Ripcord
Buffer
Tube
Water-Swellable
Tape
Water-Swellable
Tape
Water-Swellable
Tape
Polyethylene (PE)
Outer Jacket
ALTOS Lite Double-Jacket, Double-Armored
Cables, 216 Fibers, Enhanced
| Photo PIM1337
ALTOS Lite Double-Jacket, Double-Armored
Cables, 216 Fibers, Enhanced
| Photo PIM2235
Specifications
Temperature Range
Storage
Installation
Operation
-40 °C to 70 °C (-40 °F to 158 °F)
-30 °C to 70 °C (-22 °F to 158 °F)
-40 °C to 70 °C (-40 °F to 158 °F)
*
Note: Corning recommends storing cable in a proper temperature environment prior to installation to allow the cable temperature to meet installation tempera-
ture range specifications for best installation results.
Max. Tensile Strength, Short-Term
Max. Tensile Strength, Long-Term
2700 N (600 lbf)
890 N (200 lbf)
Mechanical Characteristics Cable
Fiber Count
Product Type Number of
Tube Posi-
tions
Armored
Armored
Armored
6
8
12
Number of
Weight
Active Tubes
1-6
8
12
255 kg/km
(171 lb/1000 ft)
307 kg/km
(206 lb/1000 ft)
427 kg/km
(286 lb/1000 ft)
Nominal
Outer Dia-
meter
16.1 mm
(0.63 in)
17.8 mm
(0.70 in)
21.6 mm
(0.85 in)
Min. Bend
Radius
Installation
242 mm
(9.5 in)
267 mm
(10.5 in)
324 mm
(12.8 in)
Min. Bend
Radius Ope-
ration
161 mm
(6.3 in)
178 mm
(7.0 in)
216 mm
(8.5 in)
12 - 72
96
144
Family Spec Sheet 0092_NAFTA_AEN
Page 2 | Revision date 2014-08-08
ALTOS
®
Lite™ Double-Jacket, Double-
Armored Cables, 12-216 Fibers, Enhanced
Mechanical Characteristics Cable
Fiber Count
Product Type Number of
Tube Posi-
tions
Armored
Armored
18
18
Number of
Weight
Active Tubes
16 - 18
18
420 kg/km
(282 lb/1000 ft)
420 kg/km
(282 lb/1000 ft)
Nominal
Outer Dia-
meter
21.8 mm
(0.86 in)
21.8 mm
(0.86 in)
Min. Bend
Radius
Installation
327 mm
(12.9 in)
327 mm
(12.9 in)
Min. Bend
Radius Ope-
ration
218 mm
(8.6 in)
218 mm
(8.5 in)
192 - 216
216
Chemical Characteristics
RoHS
Free of hazardous substances according to RoHS 2002/95/
EG
Transmission Performance
Multimode
Fiber Core Diameter
(
µm
)
Fiber Category
Fiber Code
Performance Option Code
Wavelengths
(
nm
)
Maximum Attenuation
(
dB/km
)
Serial 1 Gigabit Ethernet
(
m
)
Serial 10 Gigabit Ethernet
(
m
)
Min. Overfilled Launch (OFL)
Bandwidth
(
MHz*km
)
Minimum Effective Modal
Bandwidth (EMB)
(
MHz*km
)
62.5
OM1
K
30
850/1300
3.4/1.0
300/550
33/-
200/500
220/-
50
OM2
T
31
850/1300
3.0/1.0
750/500
150/-
700/500
950/-
50
OM3
T
80
850/1300
3.0/1.0
1000/600
300/-
1500/500
2000/-
50
OM4
T
90
850/1300
3.0/1.0
1100/600
550/-
3500/500
4700/-
Family Spec Sheet 0092_NAFTA_AEN
Page 3 | Revision date 2014-08-08
ALTOS
®
Lite™ Double-Jacket, Double-
Armored Cables, 12-216 Fibers, Enhanced
Single-mode
Fiber Name
Fiber Category
Fiber Code
Performance Option Code
Wavelengths
(
nm
)
Maximum Attenuation
(
dB/km
)
Typical Attenuation*
(
dB/km
)
Fiber Name
Fiber Category
Fiber Code
Performance Option Code
Wavelengths
(
nm
)
Maximum Attenuation
(
dB/km
)
Typical Attenuation*
(
dB/km
)
SMF-28e+
®
fiber
G.652.D
E
01
1310/1383/1550
0.4/0.4/0.3
0.33/0.33/0.19
LEAF
®
G.655
F
01
1310/1383/1550
-/-/0.25
-/-/0.19
SMF-28e+
®
fiber
G.652.D
E
00
1310/1383/1550
0.35/0.35/0.25
0.33/0.33/0.19
SMF-28
®
ULL
G.652
P
19
1310/1383/1550
0.33/-/0.19
0.31/-/0.17
SMF-28e+
®
LL
G.652.D
L
22
1310/1383/1550
0.34/0.34/0.22
0.32/0.32/0.18
SMF-28
®
Ultra**
ClearCurve
®
XB**
G.652.D/G.657.A1 G.652.D/G.657.A1
Z
22
1310/1383/1550
0.34/0.34/0.22
0.32/0.32/0.18
H
01
1310/1383/1550
0.4/0.4/0.3
0.35/0.35/0.20
*
Typical attenuation values match the attenuation values listed in the optical fiber specifications. See
www.corning.com/opticalfiber
for Corning optical fiber
specifications. Better attenuation performance options are available for some fiber and cable types. Contact Customer Care for additional fiber options.
*
* SMF-28
®
Ultra and ClearCurve
®
XB fiber deliver up to 10x better macrobend loss performance compared to the G.652.D standard and up to 33 percent better
macrobend loss performance than the G.657.A1 standard for 10mm radii bends.
Family Spec Sheet 0092_NAFTA_AEN
Page 4 | Revision date 2014-08-08
ALTOS
®
Lite™ Double-Jacket, Double-
Armored Cables, 12-216 Fibers, Enhanced
Ordering Information |
Note: Contact Customer Care at 1-800-743-2675 for other options.
1) Cable outer diameter may change. Example: 48 F cable with 6 fibers per tube will require 8 active buffer and have an OD like a standard 96 F cable.
Corning Optical Communications LLC • PO Box 489 • Hickory, NC 28603-0489 USA
