SANGDEST
MICROELECTRONICS
Technical Data
Data Sheet N0427, Rev. A
SMDB03LCC
THRU
SMDB24LCC
Green Products
PACKAGE OUTLINES & DEMENSIONS
MILLMETER
SYMBOL
MIN.
A
A1
A2
A3
b
c
D
E
E1
e
h
L
L1
Θ1
0
0.25
0.50
-
0.10
1.30
0.60
0.39
0.21
4.70
3.70
5.80
TYP.
-
-
1.40
0.65
-
-
4.90
3.90
6.00
1.27BSC
-
-
1.05BSC
-
MAX.
1.75
0.225
1.50
0.70
0.48
0.26
5.10
4.10
6.20
0.50
0.80
8°
SO-8
•
Weiqi Street, Airport Development Zone, Jiangning District, Nanjing, China 211113
(86) 25-87123907
•
•
FAX (86) 25-87123900
•
World Wide Web Site - http://www.sangdest.com.cn
•
E-Mail Address - sales@ sangdest.com.cn
•
SANGDEST
MICROELECTRONICS
Technical Data
Data Sheet N0427, Rev. A
SMDB03LCC
THRU
SMDB24LCC
Green Products
Ordering Information:
Device
SMDB03LCC THRU SMDB24LCC
Package
SO-8 (Pb-Free)
Shipping
2500pcs / reel
For information on tape and reel specifications, including part orientation and tape sizes, please refer to our Tape and Reel Packaging
Specification.
•
Weiqi Street, Airport Development Zone, Jiangning District, Nanjing, China 211113
(86) 25-87123907
•
•
FAX (86) 25-87123900
•
World Wide Web Site - http://www.sangdest.com.cn
•
E-Mail Address - sales@ sangdest.com.cn
•
SANGDEST
MICROELECTRONICS
Technical Data
Data Sheet N0427, Rev. A
SMDB03LCC
THRU
SMDB24LCC
Green Products
Fig.1- Peak Pulse vs. Pulse Time (
μ
s)
15
CLAMPING VOLTAGE(V)
12
9
Fig.2- Pulse Waveform (
μ
s)
SMDB05LCC
6
3
0
0
5
10
15
20
25
30
35
40
PEAK PULSE CURRENT(A)
Fig.3- Power Derating Curve
8
JUNCATION CAPACITANCE(pF)
Fig.4- Clamping Voltage vs. Peak Pulse Current
6
4
SMDB05LCC
2
0
0
1
2
3
4
5
V
BR
, REVERSE VOLTAGE(V)
Fig.3- Capacitance vs. Reverse Voltage
•
Weiqi Street, Airport Development Zone, Jiangning District, Nanjing, China 211113
(86) 25-87123907
•
•
FAX (86) 25-87123900
•
World Wide Web Site - http://www.sangdest.com.cn
•
E-Mail Address - sales@ sangdest.com.cn
•
SANGDEST
MICROELECTRONICS
Technical Data
Data Sheet N0427, Rev. A
SMDB03LCC
THRU
SMDB24LCC
Green Products
