Tri-State Enable/Disable 5.0V Oscillator
Model: H5C-2ElF
RoHS Compliant / Pb Free
Rev. 10/24/2011
http://www.foxonline.com/need_a_sample.htm
FEATURES
•
•
•
•
5.0V Operationg
HCMOS/TTL Output
Tri-State Enable/Disable
8-Pin DIP
OPTiOnS
• 14-Pin DIP Available (F5C-2ELF)
• PART nUMbER SElECTiOn
Learn More - Internet Required
Part Number
267LF-Freq-xxxxx
347LF-Freq-xxxxx
271LF-Freq-xxxxx
Model
Number
H5C-2ELF
H5C-2ERLF
H6C-2ELF
Operating
Frequency
1
Temperature (ºC)
Stability
0 ~ +70
±100PPM
-40 ~ +85
±100PPM
0 ~ +70
±50PPM
Frequency
Range (MHz)
1.500 ~ 59.000
1.500 ~ 59.000
1.500 ~ 59.000
• ElECTRiCAl CHARACTERiSTiCS
PARAMETERS
Frequency Range (F
o
)
Storage Temperature Range (T
stg
)
Supply Voltage
(V
dd
)
Input Current
(I
dd
)
1.500 ~ 40.000 MHz
40.000+ ~ 59.000 MHz
Output Symmetry (50% V
dd
)
1.500 ~ 50.000 MHz
50.000+ ~ 59.000 MHz
Rise Time (10% ~ 90% V
dd
) (T
r
)
1.500 ~ 59.000 MHz
Fall Time (90% ~ 10% V
dd
) (T
f
)
1.500 ~ 59.000 MHz
Output Voltage
(V
ol
)
(V
oh
)
Output Current
(I
ol
)
(I
oh
)
Output Load
TTL
HCMOS
Start-up Time
(T
s
)
Output Enable/Disable Time
2
1
MAX
(unless otherwise noted)
1.500 ~ 59.000 MHz
-55ºC ~ +125ºC
5.0V ± 10%
40mA
60mA
R
EC
O
M
M
EN
10 nS
10% V
dd
90% V
dd
Min
16mA Min
-16mA Min
All dimensions are in millimeters.
T
Inclusive of 25ºC tolerance, operating temperature range, input voltage change, load change, aging,
shock, and vibration.
2
An internal pullup resistor from pin 1 to V
DD
allows active output if pin 1 is left open.
All specifications subject to change without notice.
N
O
D
45% ~ 55%
40% ~ 60%
10 nS
10TTL
50pF
10mS
100nS
ED
FO
R
FOXElectronics
5570 Enterprise Parkway Fort Myers, Florida 33905 USA +1.239.693.0099 FAX +1.239.693.1554
www.foxonline.com
EMEA
Tel: +44 .1283.568153 |
Canada
+1.888.438.2369 |
Asia
Hong Kong Tel: +852.2854.4285 |
Japan
Tel: +81.3.3374.2079
© 2011 FOX ELECTRONICS | ISO9001:2008 Certified
N
EW
• EnAblE / DiSAblE FUnCTiOn
INH (Pin 1)
OUTPUT (Pin 5)
OPEN
2
ACTIVE
'1' Level V
ih
≥
2.2 V
ACTIVE
'0' Level V
il
≤
0.8 V
High Z
D
ES
I
G
N
S
