SHEET 1 OF 1
n
1.09
2.54
[.100 in]
8.13
[.320 in]
P.C. MOUNTING
n
6.00
[.236 in]
[.043 in]
.76
[.030 in]
5.08
[.200 in]
SWITCH FUNCTION
POS. 1
POS. 2
POS. 3
.38
[.015 in]
KEYWAY
ISOMETRIC
ON
2-3
OFF
OPEN
ON
2-1
POS. 1
25
~
9.40
[.370 in]
10-48UNS-2A
THREADS
E-LOGO ON
OPPOSITE SIDE
8.64
[.340 in]
1
2
3
.51
[.020 in]
POS. 2
POS. 3
n
[.100 in]
2.54
2
5.59
[.220 in]
1
3
CIRCUIT: SPDT
NOTE:
1. ALL DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X=±0.4
X.XX=±0.25
3. TERMINAL NUMBERS FOR REF ONLY
4. PLATING MATERIAL: GOLD
5. RATING: 0.4VA MAX. @20V MAX. AC OR DC
6. ELECTRIC LIFE: 30,000 MAKE-AND-BREAK CYCLES
AT FULL LOAD.
7. INSULATION RESISTANCE: 1,000 MEGA-OHM MIN.
8. DIELECTRIC STRENGTH: 1,000 V RMS @SEA LEVEL.
9. OPERATING TEMP.: -30°C to 85°C
10.
DENOTES CRITICAL PARAMETER.
NO EPOXY ON TERMINALS
BELOW THIS SURFACE
EPOXY SEAL
.51
[.020 in] TYP.
2.54
[.100 in] TYP.
3.30
[.130 in]
.76
[.030 in]
A
REV
14813
PCR NO
RELEASED FOR PRODUCTION
DESCRIPTION
4/1/05
DATE
AR
BY
TITLE
SCALE
200MSP3T1B3M2RE
2:1
DATE
DR
DWG
REV
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
4/1/05
AR
T213021
A
