1N4588(R) thru 1N4593(R)
Silicon Standard
Recovery Diode
Features
• High Surge Capability
• Types from 200 V to 800 V V
RRM
• Not ESD Sensitive
Note:
1. Standard polarity: Stud is cathode.
2. Reverse polarity (R): Stud is anode.
3. Stud is base.
DO-8 Package
V
RRM
= 200 V - 800 V
I
F
=150 A
Maximum ratings, at T
j
= 25 °C, unless otherwise specified ("R" devices have leads reversed)
Parameter
Repetitive p
p
peak reverse voltage
g
DC blocking voltage
Continuous forward current
Surge non-repetitive forward
current, Half Sine Wave
I
2
t for fusing
Operating temperature
Storage temperature
Symbol
V
RRM
V
DC
I
F
I
F,SM
I
2
t
T
j
T
stg
T
C
≤ 110 °C
T
C
= 25 °C, t
p
= 8.3 ms
60 Hz Half wave
Conditions
1N4588(R)
200
200
150
3000
37200
-55 to 150
-55 to 150
1N4590(R)
400
400
150
3000
37200
-55 to 150
-55 to 150
1N4592(R)
600
600
150
3000
37200
-55 to 150
-55 to 150
1N4593(R)
800
800
150
3000
37200
-55 to 150
-55 to 150
Unit
V
V
A
A
A
2
sec
°C
°C
Electrical characteristics, at Tj = 25 °C, unless otherwise specified
Parameter
Diode forward voltage
Reverse current
Symbol
V
F
I
R
Conditions
I
F
= 150 A, T
j
= 110 °C
V
R
= V
RRM
, T
j
= 110 °C
1N4588(R)
1.5
9.5
1N4590(R)
1.5
9
1N4592(R)
1.5
6.5
1N4593(R)
1.5
5.5
Unit
V
mA
Thermal characteristics
Thermal resistance, junction -
case
R
thJC
0.35
0.35
0.35
0.35
°C/W
Feb 2016
Latest version of this datasheet at: www.genesicsemi.com/silicon-products/standard-recovery-rectifiers/
1
1N4588(R) thru 1N4593(R)
Package dimensions and terminal configuration
Product is marked with part number and terminal configuration.
DO-8 (DO-205AA)
H
I
F
D
B
G
C
E
A
Inches
Min
A
B
C
D
E
F
G
H
I
-----
1.050
4.300
-----
0.260
-----
-----
0.276
φ0.930
1.060
4.700
0.690
-----
0.940
0.600
0.286
Max
3/8-24 UNF
-----
26.67
109.22
-----
6.50
-----
-----
7.010
Min
Millimeters
Max
φ23.5
26.92
119.38
17.00
-----
24.00
15.23
7.260
Feb 2016
Latest version of this datasheet at: www.genesicsemi.com/silicon-products/standard-recovery-rectifiers/
