SHEET 1 OF 1
12.70
[.500 in]
SWITCH FUNCTION
POS. 1
POS. 2
POS. 3
6.86
[.270 in]
KEYWAY
(ON)
2-3
OFF
OPEN
(ON)
2-1
POS. 1
25
~
POS. 2
POS. 3
1.65
[.065 in]
n
[.240 in]
6.09
(ON) = MOMENTARY
2
13.00
[.512 in]
ISOMETRIC
1
3
15/32-32 UNS-2A
.51
[.020 in]
E-SWITCH
MARKING ON
OPPOSITE SIDE
11.38
[.448 in]
CIRCUIT: SPDT
NOTE:
1. ALL DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X=±0.4
X.XX=±0.25
3. TERMINAL NUMBERS FOR REF ONLY
4. CONTACT MATERIAL: GOLD
5. RATING: 0.4 VA MAX @ 20V MAX (AC OR DC)
6. ELECTRIC LIFE: 40,000 MAKE-AND-BREAK CYCLES
AT FULL LOAD.
7. INSULATION RESISTANCE: 1,000 MEGA-OHM MIN.
8. DIELECTRIC STRENGTH: 1,000 V RMS @SEA LEVEL.
9. OPERATING TEMP.: -30°C to 85°C
10. DENOTES CRITICAL PARAMETER.
11. 2002/95/EC (ROHS) COMPLIANT
8.89
[.350 in]
EPOXY SEAL
1
.76
[.030 in]
4.70
[.185 in]
2
3
6.60
[.260 in]
1.27
[.050 in]
3
B
REV
17190
PCR NO
REVISED AND REDRAWN
DESCRIPTION
4/17/07
DATE
TN
BY
TITLE
SCALE
100SP4T7B13M2RE
2:1
DATE
DR
DWG
REV
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
4/17/2007
TN
T114084
B
