SHEET 1 OF 1
1.65
[.065 in]
n
11.91
[.469 in]
9.60
[.378 in]
n
11.91
[.469 in]
12.70
[.500 in]
6.86
[.270 in]
.79
[.031 in]
WITHOUT LOCKING RING
n
3.81
ISOMETRIC
KEYWAY
POS.
1
POS.
3
[.150 in]
WITH LOCKING RING
PANEL MOUNTING
4.70
[.185 in]
n
[.240 in]
6.09
n
1.85
[.073 in]
25°
12.37
[.487 in]
P.C. MOUNTING
SWITCH FUNCTION
POS. 1
POS. 2
POS. 3
2
15/32-32 UNS-2A
THREADS
11.38
[.448 in]
.51
[.020 in]
ON
2-3
NONE
OPEN
(ON)
2-1
1
3
E-SWITCH LOGO ON
OPPOSITE SIDE
6.60
[.260 in]
8.89
[.350 in]
CIRCUIT: SPDT
NOTE:
1. ALL DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X=±0.4
X.XX=±0.25
3. TERMINAL NUMBERS FOR REF ONLY
4. PLATING MATERIAL: GOLD
5. RATING: 0.4A @ 20V (AC or DC)
6. CONTACT RESISTANCE: 10 Milli-OHMS MAX.
6. ELECTRIC LIFE: 40,000 MAKE-AND-BREAK CYCLES
AT FULL LOAD.
7. INSULATION RESISTANCE: 1,000 Mega-OHMS MIN.
8. DIELECTRIC STRENGTH: 1,000 V RMS @SEA LEVEL.
9. OPERATING TEMP.: -30°C to 85°C
10.
DENOTES CRITICAL PARAMETER.
11. 2002/95/EC (ROHS) COMPLIANT
A
REV
18855
PCR NO
Released For Production
DESCRIPTION
3/4/10
DATE
BLR
BY
1
4.70
[.185 in]
2
3
3
EPOXY
SEAL
.76
[.030 in]
1.27
[.050 in]
TITLE
100SP2T7B13M2RE
DATE
DR
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
SCALE
2:1
DWG
REV
3/4/2010
BLR
T112060
a
