5159009321294110LF datasheet, PDF

Datasheet> All Categories > The connector> The connector> 5159009321294110LF

5159009321294110LF: DescriptionBoard Euro Connector, 32 Contact(s), 2 Row(s), Female, Straight, Solder Terminal, Receptacle, LEAD FREE; CategoryThe connector The connector; File Size93KB，1 Pages; ManufacturerAmphenol; Websitehttp://www.amphenol.com/

Download Datasheet Parametric View All

5159009321294110LF Overview

Board Euro Connector, 32 Contact(s), 2 Row(s), Female, Straight, Solder Terminal, Receptacle, LEAD FREE

5159009321294110LF Parametric

Parameter Name	Attribute value
Objectid	1633273297
package instruction	LEAD FREE
Reach Compliance Code	unknown
Body/casing type	RECEPTACLE
Connector type	BOARD EURO CONNECTOR
Contact to complete cooperation	GOLD OVER NICKEL
Contact completed and terminated	TIN
Contact point gender	FEMALE
DIN compliance	YES
Filter function	NO
IEC compliance	NO
JESD-609 code	e3
MIL compliance	NO
Manufacturer's serial number	5159009321294110LF
Mixed contacts	NO
Installation method	STRAIGHT
Installation type	BOARD
Number of rows loaded	2
Options	GENERAL PURPOSE
Terminal pitch	5.08 mm
Termination type	SOLDER
Total number of contacts	32

Preview

Download Datasheet

View All

Product Detail Page

Page 1 of 1

Direct Link

Cross reference

RoHS/LF P/N Search

Customer drawing search

3D model search

Application tooling

Services

Distributor list

Price request

Order samples

Documentation

Free search

Search by category

...

Start > Search=5159009321294110LF*

5159009321294110LF

Assistant

Email Datasheet

FCI Brings You More

Contact our sales/technical support

Sample request

Price request

Check distributor stock

Add to Favorites

Print Datasheet

5159009321294110LF

- DIN : Standard

Power Receptacle,

Type F, Vertical,

Solder-to-Board, 32

Position, 5.08 mm

(0.2 in.) Centerline

...

Specifications

Download document

General Dimensional Electrical

Certifications Other Features

General

Gender

Housing Style

Loading Pattern

Number of contacts (Total)

Number of rows (Loaded)

Orientation

Product Type

Dimensional

Length (Tail - inch)

Length (Tail)

Electrical

Current rating

Resistance (Contact)

Resistance (Insulation)

Voltage rating

Mechanical

Insertion force

Withdrawal Force

Mounting

Board attachment

Mounting ears

Physical

Material (Contact)

Material (Housing)

Plating (Tail)

Plating Specification (Contact area)

Underplating (Contact)

Temperature (Range)

Approvals / Certifications

Other Features

Packaging (Type)

Region

Type

Mechanical

Mounting

Physical

Approvals /

Receptacle

Standard

All

Z+B

Vertical

Board Connector

0.157 in.

4 mm

5.5A @ 20°

15 m ohms max.

> 1000 M ohms

1550V rms

< 1.55N per contact

>0.2N per contact

Solder-to-Board

Yes

Copper Alloy

Glass - Filled Thermoplastic Polyester

Lead-Free (Sn)

Class I

Selective Au over Ni

-55° to +125°

UL and CSA Approved

Box

Americas

Asia/Pacific

Europe

Power

http://portal.fciconnect.com/Comergent/en/US/adirect/fci?cmd=catProductDetail&showAddButton=true&productID=5159009321294110...

6/26/2009
