SHEET 1 OF 1
14.35
[.565 in]
n
1.85
3.81
[.150 in]
TYP.
1.22
[.048 in]
4.83
[.190 in]
TYP.
21.59
[.850 in]
12.70
[.500 in]
1.02
[.040 in]
[.073 in]
TYP.
KEYWAY
5.08
[.200 in]
P.C. MOUNTING
SWITCH FUNCTION
POS. 1
POS. 2
POS. 3
POS. 1
25
~
11.70
[.461 in]
ON
2-3, 5-6,
8-9, 11-12
2
5
OFF
OPEN
ON
2-1, 5-4,
8-7, 11-10
8
11
7.31
[.288 in]
.50
[.020 in]
POS. 2
.71
[.028 in]
POS. 3
2.92
[.115 in]
5.08
[.200 in]
1/4-40 UNS THREAD
T143009
1
3
4
6
7
9
10
12
14.35
[.565 in]
CIRCUIT: 4PDT
NOTE:
1. ALL DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X=±0.4
X.XX=±0.25
3. TERMINAL NUMBERS FOR REF ONLY
4. PLATING MATERIAL: GOLD
5. RATING: 0.4 (VA) MAX. @20V MAX.
6. ELECTRIC LIFE: 40,000 MAKE-AND-BREAK CYCLES
AT FULL LOAD.
3.81
7. INSULATION RESISTANCE: 1,000 MEGA-OHM MIN.
[.150 in]
.76
8. DIELECTRIC STRENGTH: 1,000 V RMS @SEA LEVEL.
[.030 in]
9. OPERATING TEMP.: -30°C to 85°C
10.
DENOTES CRITICAL PARAMETER.
11. 2002/95/EC (ROHS) COMPLIANT
12. HARDWARE TO BE SHIPPED BULK:
T100011 - LOCK WASHER, QTY 1
T100015 - LOCK RING, QTY 1
T100000 - HEX NUT, QTY 2
A
REV
21008
PCR NO
RELEASED FOR PRODUCTION
DESCRIPTION
2/7/13
DATE
10
11
12
E-SWITCH
MARKING ON
OPPOSITE SIDE
EPOXY SEAL
12
4.83
[.190 in]
9
6
3
1.27
[.050 in]
3.18
[.125 in]
EBP
BY
TITLE
1004P3T1B3M7REH
DATE
DR
DWG
REV
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
SCALE
2/7/2013
EBP
ST143009
A
