SHEET 1 OF 1
8.13
[.320 in]
FLAT
[.236 in]
n
6.00
9.14
[.360 in]
SWITCH FUNCTION
POS. 1
POS. 2
POS. 3
4.39
[.173 in]
ISOMETRIC
ON
2-3, 5-6
NONE
N/A
ON
2-1, 5-4
POS. 1
5.33
[.210 in]
25
~
POS. 3
n
2.54
[.100 in]
2
5
10-48 UNS-2A
THREADS
E-LOGO ON
OPPOSITE SIDE
1
3
4
6
CIRCUIT: DPDT
NOTE:
1. ALL DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X=±0.4
X.XX=±0.25
3. TERMINAL NUMBERS FOR REF ONLY
4. PLATING MATERIAL: GOLD
5. RATING: 0.4VA MAX. @20V AC OR DC.
6. ELECTRIC LIFE: 30,000 MAKE-AND-BREAK CYCLES
AT FULL LOAD.
7. INSULATION RESISTANCE: 1,000 MEGA-OHM MIN.
8. DIELECTRIC STRENGTH: 1,000 V RMS @SEA LEVEL.
9. OPERATING TEMP.: -30°C to 85°C
10. 2002/95/EC (ROHS) COMPLIANT
11. DENOTES CRITICAL PARAMETER.
12. HARDWARE TO BE SUPPLIED IN BULK
T200000-LOCK WASHER QTY. 1
T200002-LOCK RING
QTY. 1
T200001-HEX NUT
QTY. 2
5.59
[.220 in]
.51
[.020 in]
2.80
[.110 in]
8.64
[.340 in]
EPOXY SEAL
.51
[.020 in]
2.54
[.100 in]
2.80
4.06
[.160 in] [.110 in]
.76
[.030 in]
1.52
[.060 in]
4.06
[.160 in]
A
REV
16774
PCR NO
RELEASED FOR PRODUCTION
DESCRIPTION
12/20/06
DATE
TN
BY
TITLE
SCALE
200MDP1T2B1M1REH
2:1
DATE
DR
DWG
REV
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
12/20/2006
TN
ST201602
A
