30CTQ…
30CTQ…S
30CTQ…-1
Green Products
30CTQ…/30CTQ…S /30CTQ…-1
SCHOTTKY RECTIFIER
Applications:
•
•
•
•
•
•
•
•
•
•
•
•
•
Switching power supply
Converters
Free-Wheeling diodes
Reverse battery protection
175°C T
J
operation
Center tap configuration
Low forward voltage drop
High purity, high temperature epoxy encapsulation for enhanced mechanical strength and
moisture resistance
High frequency operation
Guard ring for enhanced ruggedness and long term reliability
This is a Pb
−
Free Device
All SMC parts are traceable to the wafer lot
Additional testing can be offered upon request
Features:
30CTQ…
Case styles
30CTQ…S
30CTQ…-1
TO-220AB
D
2
PAK
Mechanical Dimensions: In Inches / mm
TO-262
TO-220AB
•
Weiqi Street, Airport Development Zone, Jiangning District, Nanjing, China 211113
(86) 25-87123907
•
•
FAX (86) 25-87123900
•
World Wide Web Site - http://www.sangdest.com.cn
•
E-Mail Address - sales@ sangdest.com.cn
•
SANGDEST
MICROELECTRONICS
Technical Data
Data Sheet N0281, Rev. -
30CTQ…
30CTQ…S
30CTQ…-1
Green Products
Symbol
A
A1
A2
b
b1
c
c1
D
D1
E
E1
E2
e
H
L
L1
L2
L3
e
e1
e2
e3
Dimensions in
millimeters
Min. Typical Max.
4.55
0
2.59
0.71
0.36
1.17
8.55
6.40
10.01
7.6
9.98
14.6
2.00
1.17
4.70
0.10
2.69
0.81
1.27
0.38
1.27
8.70
10.16
10.08
2.54
15.1
2.30
1.27
0.25BSC
-
5°
4°
4°
4.85
0.25
2.89
0.96
0.61
1.37
8.85
10.31
10.18
15.6
2.70
1.40
2.20
8°
0
D
2
PAK
TO-262
•
Weiqi Street, Airport Development Zone, Jiangning District, Nanjing, China 211113
(86) 25-87123907
•
•
FAX (86) 25-87123900
•
World Wide Web Site - http://www.sangdest.com.cn
•
E-Mail Address - sales@ sangdest.com.cn
•
SANGDEST
MICROELECTRONICS
Technical Data
Data Sheet N0281, Rev. -
30CTQ…
30CTQ…S
30CTQ…-1
Green Products
Marking Diagram:
Where XXXXX is YYWWL
30CTQ035
SSG
YY
WW
L
=Part Name
= SSG
= Year
= Week
= Lot Number
30CTQ035
Cautions：
Molding resin
Epoxy resin UL:94V-0
30CTQ035S
Ordering Information:
Device
30CTQ…
30CTQ…S
Package
TO-220AB
(Pb-Free)
D²PAK
(Pb-Free)
Shipping
50pcs / tube
800pcs / reel
For information on tape and reel specifications, including part orientation and tape sizes, please refer to our Tape and Reel Packaging
Specification.
Maximum Ratings:
Characteristics
Peak Inverse Voltage
Symbol
V
RWM
Condition
-
Max.
35(30CTQ035)
40(30CTQ040)
45(30CTQ045)
30
Units
V
Max. Average Forward
Max. Peak One Cycle
Non-Repetitive Surge Current
(per leg)
I
F(AV)
50% duty cycle @T
C
= 127°C,
rectangular wave form
8.3 ms, half Sine pulse
A
I
FSM
318
A
•
Weiqi Street, Airport Development Zone, Jiangning District, Nanjing, China 211113
(86) 25-87123907
•
•
FAX (86) 25-87123900
•
World Wide Web Site - http://www.sangdest.com.cn
•
E-Mail Address - sales@ sangdest.com.cn
•
SANGDEST
MICROELECTRONICS
Technical Data
Data Sheet N0281, Rev. -
30CTQ…
30CTQ…S
30CTQ…-1
Green Products
Electrical Characteristics:
Characteristics
Max. Forward Voltage Drop
(per leg) *
Max. Reverse Current
(per leg) *
Symbol
V
F1
V
F2
I
R1
I
R2
Max. Junction Capacitance
(per leg)
Max. Voltage Rate of Change
*
Pulse Width < 300µs, Duty Cycle <2%
C
T
dv/dt
Condition
@ 15A, Pulse, T
J
= 25
°C
@ 15A, Pulse, T
J
= 125
°C
@V
R
= rated V
R
T
J
= 25
°C
@V
R
= rated V
R
T
J
= 100°C
@V
R
= 5V, T
C
= 25
°C
f
SIG
= 1MHz
-
Max.
0.62
0.56
1.0
15
900
10,000
Units
V
V
mA
mA
pF
V/μs
Thermal-Mechanical Specifications:
Characteristics
Max. Junction Temperature
Max. Storage Temperature
Maximum Thermal
Resistance Junction to Case
Approximate Weight
Case Style
Symbol
T
J
T
stg
R
θJC
Condition
-
-
DC operation
Specification
-55 to +175
-55 to +175
3.25
Units
°C
°C
°C/W
wt
-
2/1.85
g
2
2
TO-220AB D PAK TO-262(Suffix”-1” for TO-262;”S” for D PAK)
•
