SHEET 1 OF 1
LED SPECS
FORWARD CURRENT
FORWARD VOLTAGE @ 20mA
LUMINOUS INTENSITY @ 20mA
UNITS
mA
V
MCD
RED
20
1.95 - 2.5
3,000
GREEN
20
2.1-2.5
400
2.54
[.100 in]
3
(-)
1
5.08
[.200 in]
6.00
[.236 in]
HALO
TRANSLUCIENT
GRAPHIC
n
8.50
[.335 in]
5.08
[.200 in]
4
2.54
[.100 in]
5.40
[.213 in]
7.60
[.299 in]
(+)
P.C.B. LAYOUT
2
n
1.00
[.039 in]
-
RED
+
5
3
1
GRN
6
4
2
1.40
[.055 in]
7.00
[.276 in]
BLACK BUTTON
BLACK BEZEL
RED / GREEN LED
CIRCUIT: SPST
8.50
[.335 in]
DOT MARKING
INDICATES
CATHODE
3.50
[.138 in]
5.50
[.217 in]
.40
[.016 in]
NOTES:
1. ALL DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X=±0.4
X.XX=±0.25
3. RATING: 12VDC @ 50mA
4. CONTACT RESISTANCE: 100m
W
MAX.
5. INSULATION RESISTANCE: 100M
W
MIN.
6. OPERATING FORCE: 180
`
50gf
7. TRAVEL: 0.2
`
0.1mm
8. OPERATING TEMPERATURE: -20
~
C TO 70
~
C
9. OPEREATING LIFE: 500,000 CYCLES
10. LED COLOR: RED / GREEN
11. DENOTES CRITICAL PARAMETERS
12. 2002/95/EC (ROHS) COMPLIANT
13. PARTS TO BE PACKAGE 100 PARTS PER TRAY.
1
.70
[.028 in]
.50
[.020 in]
(-)
(+)
LOCATING PIN
3
5.08
[.200 in]
5.08
[.200 in]
.30
[.012 in]
(-)
3
4
4.00
[.157 in]
(+)
5.40
[.213 in]
A
REV
19982
PCR NO
RELEASE FOR PRODUCTION
DESCRIPTION
6/6/11
DATE
BGL
BY
TITLE
SCALE
TL1220R1BBBRG-HALO
4
DATE
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
6/6/2011
DR
BGL
DWG
B260015
REV
A
