SHEET 1 OF 1
3
4
6.80
[.268 in]
[.197 in]
1
_ 5
2
6 +
7.00
[.276 in]
n
5.00
CIRCUIT: SPST
LED COLOR
RED
3.00
[.118 in]
5
1
3
n
1.00
[.039 in]
4 PLS
3.00
[.118 in]
4.50
[.177 in]
n
8.00
[.315 in]
CAP COLOR:
TRANSPARENT
PES MATERIAL
6.30
[.248 in]
5.80
[.228 in]
12.00
[.472 in]
.90
[.035 in]
4.50
[.177 in]
1.00
[.039 in]
3.00
[.118 in]
2.30
[.091 in]
2
4
6
PCB LAYOUT
n
.80
[.031 in]
2 PLS
NOTES:
1. ALL DIMENSIONS IN MM
2. GENERAL TOLERANCE: X.X=±0.4
X.XX=±0.25
3. RATING: 50mA, 12VDC
4. TRAVEL: 0.2 ±0.1
5. OPERATING FORCE: 160±50gf
6. CONTACT RESISTANCE: 100m-Ohms MAX
7. CONTACT MATERIAL: SILVER
8. OPERATING LIFE: 500,000 CYCLES
9. INSULATION RESISTANCE: 100M-Ohms MIN
10. DIELECTRIC STRENGTH: 500VDC FOR 1 MINUTE
11. LED COLOR: RED
12. OPERATING TEMPERATURE: -20° C TO 70° C
13. 2002/95/EC (ROHS) COMPLIANT
14. DENOTES CRITICAL PARAMETER
3.00
[.118 in]
4.50
[.177 in]
.70
[.028 in]
5
1
3
6
5.00
[.197 in]
.30
[.012 in]
.20
[.008 in]
3.00
[.118 in]
6.00
[.236 in]
3
6
4
6.30
[.248 in]
RED LED
20
1.95 TYP. - 2.5 MAX
1,800
LED SPECS
FORWARD CURRENT
FORWARD VOLTAGE
LUMINOUS INTENSITY
UNITS
mA
V
mcd
A
REV
19986
PCR NO
RELEASE FOR PRODUCTION
DESCRIPTION
6/8/11
DATE
BGL
BY
TITLE
SCALE
TL1265RQSCLR
3:1
DATE
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
6/8/2011
DR
BGL
DWG
B200024
REV
A
