SHEET 1 OF 1
8.00
[.315 in]
3.25
[.128 in]
5.00
[.197 in]
2.00
[.079 in]
9.30
[.366 in]
1.40
[.055 in]
1
3
5
3.40
[.134 in]
1
2
5.40
[.213 in]
2
.60
[.024 in]
4
6.30
[.248 in]
6
BLUE
LED
1.20
[.047 in]
.20
[.008 in]
6.80
[.268 in]
YELLOW
LED
2.30
[.091 in]
PC MOUNTING
1
+ 3
+ 5
BLUE
YELLOW
2
4 -
6 -
1
3.25
[.128 in]
2
2.50
[.098 in]
2.00
[.079 in]
4
6
CIRCUIT
4.50
[.177 in]
4
6
NOTES:
1. ALL DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X=
`
0.4
X.XX=
`
0.25
3. RATING: 12VDC, 50mA MAX.
4. CONTACT RESISTANCE: 500m
W
MAX.
5. INSULATION RESISTANCE: 100VDC, 100M
W
MIN.
6. TRAVEL: 0.25 mm
7. OPERATING FORCE: 160 +75/-30gf
8. OPERATING TEMPURATURE: -20
~
C TO 70
~
C
9. OPERATING LIFE: 30,000 CYCLES.
10. PACKAGING: TAPE & REEL, 3000 PIECES PER REEL
11. DENOTES CRITICAL PARAMETER
12. 2002/95/EC (ROHS) COMPLIANT
1
2
LED Specifications
Forward Current
Units
mA
V
mcd
BLUE
20
2.8 MIN
3.3 MAX
80 TYP
YELLOW
20
2.0 TYP
2.5MAX
160 TYP
.50
[.020 in]
3
5
Forward Voltage
Luminous Intensity@20mA
A
REV
20604
PCR NO
RELEASED FOR PRODUCTION
DESCRIPTION
5/14/12
DATE
rc
BY
TITLE
SCALE
TL3200AF160BYQ
8:1
