39B datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> 39B

Preview

39B: DescriptionUNSHIELDED, 2 uH - 4 uH, VARIABLE INDUCTOR; CategoryPassive components; File Size109KB，2 Pages; ManufacturerDIOTEC; Websitehttp://www.diotec.com/

Download Datasheet View All

39B Overview

UNSHIELDED, 2 uH - 4 uH, VARIABLE INDUCTOR

Preview

Download Datasheet

View All

MM3Z2B4 ... MM3Z47B (200 mW - 2%)

Surface mount Silicon Planar Zener Diodes

Silizium-Planar-Zener-Dioden für die Oberflächenmontage

Version 2012-08-22

Maximum power dissipation

Maximale Verlustleistung

1.7

±0.1

200 mW

2.4...47 V

~ SOD-323

0.01 g

Nominal Z-voltage – Nominale Z-Spannung

Plastic case

Kunststoffgehäuse

1.25

±0.1

Type

Code

±0.1

Weight approx. – Gewicht ca.

Plastic material has UL classification 94V-0

Gehäusematerial UL94V-0 klassifiziert

Standard packaging taped and reeled

Standard Lieferform gegurtet auf Rolle

0.3

2.5

±0.2

Dimensions - Maße [mm]

Standard Zener voltage tolerance is graded to the international E 24 (~5%) standard.

Other voltage tolerances and higher Zener voltages on request.

Die Toleranz der Zener-Spannung ist in der Standard-Ausführung gestuft nach der internationalen

Reihe E 24 (~5%). Andere Toleranzen oder höhere Arbeitsspannungen auf Anfrage.

Maximum ratings and Characteristics

Power dissipation

Verlustleistung

Junction temperature − Sperrschichttemperatur

Storage temperature – Lagerungstemperatur

Thermal resistance junction to ambient air

Wärmewiderstand Sperrschicht – umgebende Luft

= 25°C

tot

Grenz- und Kennwerte

MM3Z-series

200 mW

)

-50...+150°C

< 620 K/W

)

thA

Zener voltages see table on next page – Zener-Spannungen siehe Tabelle auf der nächsten Seite

[mA]

5,1

4,7

4,3

3,9

= 5 mA

3,6

3,3

5,6

6,2

6,8

7,5

8,2

9,1

3,0

2,7

2,4

[V]

Zener Voltage vs. Zener current

–

Abbruchspannung über Zenerstrom

Mounted on P.C. board with 3 mm

copper pads at each terminal

Montage auf Leiterplatte mit 3 mm

Kupferbelag (Lötpad) an jedem Anschluss

http://www.diotec.com/
