SHEET 1 OF 1
10.60
[.417 in]
B
4.70
[.185 in]
10.30
[.406 in]
n
1.60
[.063 in]
O.P. (MM)
15.5
`
0.8
P.T. (MM)
4.1 MAX.
B
36.00
`
.50
[1.417
`
.020
in]
ISOMETRIC
O.P. = OPERATING POINT
P.T. = PRE-TRAVEL
27.90
[1.098 in]
P.T.
NC
COM
NO
CIRCUIT: SPDT
O.P.
10.40
[.409 in]
22.20
[.874 in]
1.00
[.039 in]
4.30
[.169 in]
n
3.10
[.122 in]
5.35
[.211 in]
3.15
[.124 in]
.50
[.020 in]
n
3.40
15.90
[.626 in]
NOTES:
1. ALL DIMENSIONS IN MM [INCH]
3.10
2. GENERAL TOLERANCE: X.X=
`
0.4
[.122 in]
X.XX=
`
0.25
2.75
3. RATING: 15A @125/250VAC UL, CUL, VDE APPROVED
[.108 in]
4. OPERATING FORCE: 120
`
40 GRAMS
5. OPERATING TEMP: -25
~
C TO 85
~
C
6. ELECTRICAL LIFE: 50,000 CYCLES MIN.
7. MECHANICAL LIFE: 1,000,000 CYCLES TYP.
8. INSULATION RESISTANCE: 100 MEGA-OHMS MIN.
9. DIELECTRIC STRENGTH: 1500VAC 1 MINUTE (INITAL VALUE)
10. CONTACT RESISTANCE: 100 MILLI -OHMS MAX.
11.
DENOTES CRITICAL PARAMETER.
12. 2002/95/EC (ROHS) COMPLIANT
13. PACKAGE: 100 PCS/CASE, 13 CASES/BOX, 1,300 PCS TOTAL
B
A
REV
20755
17048
PCR NO
36.00 WAS 36.6, 4.70 WAS 4.75
RELEASED FOR PRODUCTION
DESCRIPTION
9/17/12
3/1/07
DATE
EBP
TN
BY
[.134 in]
7.60
[.299 in]
TITLE
LS0851502F120C1A
1.5:1
DATE
DR
DWG
REV
