RoHS
Radial Power Choke
Dimensions:
.551
(14.0)
MAX.
RB1315
Inches
(mm)
.669
(17.0)
MAX.
.295±.020
(7.50±0.5)
.031±.002
(0.80±0.05)
.197±..020
(5.00±0.5)
Allied
Part
Number
Inductance Tolerance
(µh)
(%)
@ 1KHz
Q
Min.
Q
SRF
Test Freq Min.
(MHz) (MHz)
DCR
Max.
(Ω)
Isat Irms
(A)
(A)
Max. Max.
Features
RB1315-100K-RC
RB1315-120K-RC
RB1315-220K-RC
RB1315-330K-RC
RB1315-470K-RC
RB1315-680K-RC
RB1315-101K-RC
RB1315-151K-RC
RB1315-221K-RC
RB1315-331K-RC
RB1315-471K-RC
RB1315-681K-RC
RB1315-102K-RC
RB1315-152K-RC
RB1315-222K-RC
RB1315-332K-RC
RB1315-472K-RC
RB1315-682K-RC
RB1315-103K-RC
10
12
22
33
47
68
100
150
220
330
470
680
1000
1500
2200
3300
4700
6800
10000
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
90
90
80
70
50
40
50
50
40
30
30
30
30
40
40
40
40
30
70
2.520
2.520
2.520
2.520
2.520
2.520
0.796
0.796
0.796
0.796
0.796
0.796
0.252
0.252
0.252
0.252
0.252
0.252
.0796
19
12
7.6
6.9
5.6
4.4
3.3
2.6
2.2
1.8
1.5
1.2
1.00
.83
.70
.60
.43
.38
.30
.023
.028
.035
.043
.052
.068
.097
0.14
0.20
0.30
0.43
0.61
1.00
1.30
2.00
3.10
4.40
6.50
10.0
12
9.5
8.2
6.8
5.7
4.8
3.9
3.2
2.7
2.1
1.8
1.5
1.2
1.0
.83
.69
.58
.46
.40
5.1
4.5
4.2
3.7
3.4
3.0
2.5
2.1
1.7
1.4
1.1
.99
.78
.68
.55
.44
.37
.30
.24
•
•
•
•
High Current
LOW DCR
Extensive Inductance Range
Extended Temperature Range
Electrical
Inductance Range:
10uh ~ 10,000uh
Tolerance:
10% over entire range.
Test Frequency:
as noted
Operating Temperature:
-55ºC to +
125ºC.
Isat:
Based on Inductance change by
no more than 10% of initial value.
Irms:
Based on a temperature rise of
25ºC.
Temperature:
Under no conditions
should the temperature of the part
exceed 125ºC
Test Equipment
Inductance:
HP4363B
DCR:
HP4263B + Current Source DCR
Meter
Current:
11021 Current Source & DCR
Meter
Physical
Packaging:
Bulk
Marking:
EIA Inductance Code
All specifications subject to change without notice.
949-356-1780
ALLIED COMPONENTS INTERNATIONAL
04/08/2014
www.alliedcomponents.com
