RoHS
Radial Leaded 4 Pin Bobbin Coil
RB4P1010
Dimensions:
(mm)
A:
B:
C:
D:
E:
F:
10±0.5
10±0.5
3.5±1.0
0.7+0.1/-0.05
4.0±0.3
5.0±0.3
Allied
Part
Number
*
Inductance Tolerance
(µh)
Test Freq
SRF
(MHz)
Min
DCR
(Ohms)
Max
Features
Rated
Current
(mA)
RB4P1010-100M-_ _
RB4P1010-120M-_ _
RB4P1010-150M-_ _
RB4P1010-180M-_ _
RB4P1010-220K-_ _
RB4P1010-270K-_ _
RB4P1010-330K-_ _
RB4P1010-390K-_ _
RB4P1010-470K-_ _
RB4P1010-560K-_ _
RB4P1010-680K-_ _
RB4P1010-820K-_ _
RB4P1010-101K-_ _
RB4P1010-121K-_ _
RB4P1010-151K-_ _
RB4P1010-181K-_ _
RB4P1010-221K-_ _
RB4P1010-271K-_ _
RB4P1010-331K-_ _
RB4P1010-391K-_ _
RB4P1010-471K-_ _
RB4P1010-561K-_ _
RB4P1010-681K-_ _
RB4P1010-821K-_ _
RB4P1010-102K-_ _
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
20%
20%
20%
20%
20%
20%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
2.52MHz
2.52MHz
2.52MHz
2.52MHz
2.52MHz
2.52MHz
2.52MHz
2.52MHz
2.52MHz
2.52MHz
2.52MHz
2.52MHz
1KHz
1KHz
1KHz
1KHz
1KHz
1KHz
1KHz
1KHz
1KHz
1KHz
1KHz
1KHz
1KHz
14
11
7.7
7.1
6.8
6.1
6.0
8.6
8.1
7.6
6.3
6.0
5.7
4.8
4.2
3.9
3.8
3.4
2.8
2.7
2.5
2.2
2.1
2.0
1.7
0.022
0.023
0.026
0.033
0.037
0.048
0.055
0.073
0.083
0.092
0.120
0.140
0.160
0.200
0.230
0.310
0.340
0.400
0.520
0.650
0.710
1.00
1.10
1.30
1.70
5300
4900
4400
4000
3600
3300
2900
2700
2500
2300
2100
1900
1700
1500
1400
1300
1100
1000
930
860
780
710
650
590
530
•
•
•
For Power, RF and other applications
4 Pins Design for rugged mounting
UL Polyolefin Tubing Optional
Electrical
Inductance Range:
-10µh ~ 10,000µh
others available.
Tolerance:
As shown
Test Frequency:
10uh to 82uh @ 2.52MHz,
Operating Temperature:
-55ºC to +125ºC
Rated Current:
Current at which the
Inductance values will decrease by no more
than 10% from initial value.
Test Equipment
Inductance:
HP4342A / HP4342A
DCR:
CH-301 Current Source & DCR Meter
Current:
CH-301 Current Source & DCR Meter
Current:
9461L
*
To add shrink tubing, add “ST” to part number.
All specifications subject to change without notice.
Physical
Packaging:
400pcs Tray 3200 / Ctn
Marking:
none
949-356-1780
ALLIED COMPONENTS INTERNATIONAL
08/07/2014
www.alliedcomponents.com
