RoHS
VERTICAL MOUNT POWER CHOKE
RVC1
Dimensions:
Inches
(mm)
Features
Allied
Part
Number
RVC1-15-1R5L
RVC1-10-1R8L
RVC1-15-1R8L
RVC1-3-4R7L
RVC1-5-4R7L
RVC1-10-4R7L
RVC1-3-100K
RVC1-5-100K
RVC1-10-100K
RVC1-10-150K
RVC1-3-220K
RVC1-5-220K
RVC1-10-220K
RVC1-3-470K
RVC1-5-470K
RVC1-10-470K
RVC1-3-101K
RVC1-5-101K
RVC1-3-181K
RVC1-5-301K
RVC1-5-391K
L
(µh)
1.5±15%
1.8±15%
1.8±15%
4.7±15%
4.7±15%
4.7±15%
10±10%
10±10%
10±10%
15±10%
22±10%
22±10%
22±10%
47±10%
47±10%
47±10%
100±10%
100±10%
180±10%
300±10%
390±10%
Rated Current DCR
(Amps)
(Ohm)
Max
18.2
18.2
19.3
7.5
9.1
11.8
6.0
7.1
10.9
11.8
5.5
6.9
10.4
5.3
6.3
8.2
3.4
4.9
2.8
3.4
3.0
0.003
0.006
0.003
0.021
0.012
0.012
0.026
0.020
0.013
0.020
0.035
0.023
0.018
0.050
0.033
0.022
0.072
0.055
0.150
0.160
0.190
A
Max
.65/16.5
.65/16.5
.65/16.5
.62/15.7
.62/15.7
.62/15.7
.63/16.0
.62/15.7
.63/16.0
.70/17.8
.62/15.7
.62/15.7
.70/17.8
.65/16.5
.90/22.9
.90/22.9
.90/22.9
.90/22.9
.63/18.0
1.1/27.9
1.7/27.9
B
Max
.90/22.9
1.1/27.9
1.1/27.9
.85/21.6
.85/21.6
1.1/27.9
.85/21.6
.85/21.6
1.1/27.9
1.4/35.6
1.1/27.9
1.1/27.9
1.2/30.5
1.4/35.6
1.3/33.1
1.4/35.6
1.3/33.1
1.4/35.6
1.2/30.5
1.0/25.4
1.0/25.4
C
D
.42/10.7 .068/1.73
.42/10.7 .054/1.37
.42/10.7 .068/1.73
.42/10.7 .035/0.89
.42/10.7 .042/1.07
.42/10.7 .054/1.37
.42/10.7 .035/0.89
.42/10.7 .042/1.07
.42/10.7 .054/1.37
.42/10.7 .060/1.52
.42/10.7 .035/0.89
.42/10.7 .042/1.07
.42/10.7 .060/1.52
.42/10.7 .035/0.89
.70/17.8 .042/1.07
.70/17.8 .060/1.52
.70/17.8 .035/.089
.70/17.8 .042/1.07
.42/10.7 .028/0.71
.70/17.8 .038/0.97
.70/17.8 .038/0.97
•
•
•
•
•
•
High Current
Low DC Resistance
High Temp Range
Insulated Base
Shrink Tubing Optional
Various sizes and Values Available
Electrical
Inductance Range:
1.5uh to 390uh
Tolerance:
15% from 1.5uH to 4.7uh,
10% from 10uH to 390uh
Test Frequency:
15.75Khz
Operating Temp:
-55ºC to + 125ºC
Rated Current:
Based on Inductance drop
of not more than < 10% of initial value
Test Equipment
(L):
CH-100, 1KHz LCR Meter
(RDC):
CH-301 Current source and DCR
Meter
(IDC):
10 Sec ± 1 sec.
All specifications subject to change without notice.
Physical
Packaging:
Bulk
Marking:
EIA Inductance Code
714-665-1140
ALLIED COMPONENTS INTERNATIONAL
9/23/2013
15
www.alliedcomponents.com
