SHEET 1 OF 1
2.54
[.100 in]
REAL CODE
C 1 2 4 8
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
n
3.20
[.126 in]
2.54
[.100 in]
n
.80
[.031 in]
8
C
2
2.54
[.100 in]
2.70
[.106 in]
1
C
4
P.C. LAYOUT
7.40
[.291 in]
5.80
[.228 in]
7.40
[.291 in]
NOTES:
1. ALL DIMESNIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X=
`
0.4
X.XX=
`
0.25
3. TERMINAL NUMBERS FOR REFERENCE ONLY
4. OPERATING FORCE: 120gf/cm
`
30gf
5. CONTACT RATING: 100mA, 42V DC (SWITCHING)
400mA 42V DC (NON-SWITCHING)
6. CONTACT RESISTANCE: 80m
W
MAX.
7. INSULATION RESISTANCE: 100M
W
MIN @ 250VDC
8. DIELECTRIC STRENGTH: 250VAC 1 MIN.
9. LIFE: 25,000 STEPS
10. OPERATING TEMPERATURE: -60
~
C TO 125
~
C
11. PACKAGING:65 PCS TUBE
12. IP RATING: IP67
13. DENOTES CRITICAL PARAMETER
14. 2002/95/EC (ROHS) COMPLIANT
3.50
[.138 in]
1
.48
[.019 in]
2.54
[.100 in]
C
4
2.54
[.100 in]
2.70
[.106 in]
4
2
.25
[.010 in]
2.54
[.100 in]
A
REV
21365
PCR NO
NEW RELEASE
DESCRIPTION
1/31/14
DATE
EBP
BY
TITLE
RDMAR16R2T
DATE
DR
DWG
REV
