SHEET 1 OF 1
2.60
[.102 in]
8
C
2
1.20
[.047 in]
2.54
[.100 in]
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
REAL CODE
C 1 2 4 8
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
n
4.10
[.161 in]
[.378 in]
n
9.60
1
C
4
14.60
[.575 in]
10.00
[.394 in]
PCB LAYOUT
10.00
[.394 in]
12.00
[.472 in]
2.54
[.100 in]
5.08
[.200 in]
2.20
[.087 in]
6.50
[.256 in]
4
.20
[.008 in]
2
6.80
[.268 in]
.54
[.021 in]
2
C
8
NOTES:
1. ALL DIMESNIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X=
`
0.4
X.XX=
`
0.25
3. TERMINAL NUMBERS FOR REFERENCE ONLY
4. OPERATING FORCE: 700gf/cm MAX.
5. CONTACT RATING: 150mA, 42V DC (SWITCHING)
200mA 42V DC (NON-SWITCHING)
6. CONTACT RESISTANCE: 80m
W
MAX.
7. INSULATION RESISTANCE: 100M
W
MIN @ 250VDC
8. DIELECTRIC STRENGTH: 250VAC 1 MIN.
9. LIFE: 10,000 STEPS
10. OPERATING TEMPERATURE: -60
~
C TO 125
~
C
11. PACKAGING: 600 PCS TAPE AND REEL
12.
DENOTES CRITICAL PARAMETER
13. 2002/95/EC (ROHS) COMPLIANT
B
A
REV
20569
20559
PCR NO
Revised REAL CODE Chart
RELEASE TO PRODUCTION
DESCRIPTION
4/25/12
4/20/12
DATE
rc
rc
BY
4
C
1
2
C
8
TITLE
SCALE
RDTCR16S1RCUSTMARK
2:1
DATE
DR
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
4/20/2012
rc
DWG
REV
U200016
B
