SHEET 1 OF 1
REAL CODE
C 1 2 4 8
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
CROSS
ACTUATOR
9.80
[.386 in]
R4.80
[.189 in]
NOTES:
1. ALL DIMESNIONS IN mm [INCH]
2. GENERAL TOLERANCE: X.X=
`
0.4
X.XX=
`
0.25
3. TERMINAL NUMBERS FOR REFERENCE ONLY
4. OPERATING FORCE: 700gf/cm MAX.
5. CONTACT RATING: 150mA, 42V DC (SWITCHING)
200mA 42V DC (NON-SWITCHING)
6. CONTACT RESISTANCE: 80m
W
MAX.
7. INSULATION RESISTANCE: 100M
W
MIN @ 250VDC
8. DIELECTRIC STRENGTH: 250VAC 1 MIN.
9. LIFE: 10,000 STEPS
10. OPERATING TEMPERATURE: -40
~
C TO 85
~
C
11. PACKAGING: 50 PCS PER TUBE
12.
DENOTES CRITICAL PARAMETER
13. 2002/95/EC (ROHS) COMPLIANT
.46
[.018 in]
8
1
C
C
2
4
2.54
[.100 in]
n
1.00
[.039 in]
6X
6.80
[.268 in]
2.54
[.100 in]
FRONT OF SWITCH
PCB LAYOUT
2.54
[.100 in]
10.00
[.394 in]
10.00
[.394 in]
3.50
[.138 in]
1
.54
[.021 in]
C
4
2.20
[.087 in]
2.54
[.100 in]
2.54
[.100 in]
4.60
[.181 in]
4
2
.20
[.008 in]
2.54
[.100 in]
A
REV
20620
PCR NO
INITIAL RELEASE
DESCRIPTION
06/05/12
DATE
drg
BY
TITLE
SCALE
RDTCR16R2T
