SHEET 1 OF 1
2.54
[.100 in]
6.80
[.268 in]
2
C
4
C
1
2.54
[.100 in]
n
1.00
[.039 in]
PCB LAYOUT
.54
[.021 in]
REAL CODE
C 1 2 4
0
1
2
3
4
5
6
7
C
2
1
C
4
2.54
[.100 in]
3.50
[.138 in]
10.00
[.394 in]
n
9.60
[.378 in]
n
4.10
[.161 in]
2.54
[.100 in]
10.00
[.394 in]
NOTES:
1. ALL DIMESNIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X=
`
0.4
X.XX=
`
0.25
3. TERMINAL NUMBERS FOR REFERENCE ONLY
4. OPERATING TORQUE: 700gf-cm MAX.
5. CONTACT RATING: 150mA, 42V DC (SWITCHING)
200mA 42V DC (NON-SWITCHING)
6. CONTACT RESISTANCE: 80m
W
MAX.
7. INSULATION RESISTANCE: 100M
W
MIN @ 250VDC
8. DIELECTRIC STRENGTH: 250VAC 1 MIN.
9. LIFE: 10,000 STEPS
10. OPERATING TEMPERATURE: -40
~
C TO 85
~
C
11. PACKAGING:50 PCS TUBE
12. IP RATING: IP67
13. DENOTES CRITICAL PARAMETER
14. 2002/95/EC (ROHS) COMPLIANT
4.60
[.181 in]
6.30
[.248 in]
9.80
[.386 in]
6.80
[.268 in]
2.20
[.087 in]
2.54
[.100 in]
.20
[.008 in]
A
REV
21521
PCR NO
RELEASE TO PRODUCTION
DESCRIPTION
7/22/14
DATE
EBP
BY
TITLE
RDTBR08R2T
DATE
DR
DWG
REV
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
SCALE
7/22/2014
EBP
U200033
A
