KSC5603DTU

Description
NPN Silicon Transistor, Planar Silicon Transistor
CategoryDiscrete semiconductor    The transistor
File Size107KB,5 Pages
ManufacturerFairchild
Websitehttp://www.fairchildsemi.com/
Environmental Compliance
Download Datasheet Parametric View All

KSC5603DTU Online Shopping

Suppliers Part Number Price MOQ In stock
KSC5603DTU - - View Buy Now

KSC5603DTU Overview

NPN Silicon Transistor, Planar Silicon Transistor

KSC5603DTU Parametric

Parameter NameAttribute value
Brand NameFairchild Semiconduc
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerFairchild
Parts packaging codeTO-220
package instructionFLANGE MOUNT, R-PSFM-T3
Contacts3
Manufacturer packaging code3LD, TO220, JEDEC, MOLDED
Reach Compliance Codecompli
ECCN codeEAR99
Maximum collector current (IC)3 A
Collector-emitter maximum voltage800 V
ConfigurationSINGLE WITH BUILT-IN DIODE
Minimum DC current gain (hFE)20
JEDEC-95 codeTO-220AB
JESD-30 codeR-PSFM-T3
JESD-609 codee3
Number of components1
Number of terminals3
Maximum operating temperature150 °C
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formFLANGE MOUNT
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Polarity/channel typeNPN
Maximum power dissipation(Abs)3 W
Certification statusNot Qualified
surface mountNO
Terminal surfaceMatte Tin (Sn)
Terminal formTHROUGH-HOLE
Terminal locationSINGLE
Maximum time at peak reflow temperatureNOT SPECIFIED
transistor applicationsSWITCHING
Transistor component materialsSILICON
Nominal transition frequency (fT)11 MHz
KSC5603D — NPN Silicon Transistor, Planar Silicon Transistor
February 2010
KSC5603D
NPN Silicon Transistor, Planar Silicon Transistor
Features
High Voltage High Speed Power Switch Application
Wide Safe Operating Area
Built-in Free Wheeling Diode
Suitable for Electronic Ballast Application
Small Variance in Storage Time
Equivalent Circuit
C
B
1
E
TO-220
2.Collector
3.Emitter
1.Base
Absolute Maximum Ratings
Symbol
V
CBO
V
CEO
V
EBO
I
C
I
CP
I
B
I
BP
P
C
T
J
T
A
= 25°C unless otherwise noted
Parameter
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Current (DC)
*Collector Current (Pulse)
Base Current (DC)
*Base Current (Pulse)
Power Dissipation(T
C
=25°C)
Junction Temperature
Value
1600
800
12
3
6
2
4
100
150
-65 to +150
Units
V
V
V
A
A
A
A
W
°C
°C
T
STG
Storage Temperature
* Pulse Test: Pulse Width=5ms, Duty Cycle<10%
Thermal Characteristics
Symbol
R
θJC
R
θJA
T
L
T
A
= 25°C unless otherwise noted
Parameter
Thermal Resistance
Junction to Case
Junction to Ambient
Maximun Lead Temperature for Soldering Purpose
: 1/8” from Case for 5 seconds
Rating
1.25
80
270
Units
°C/W
°C/W
°C
© 2010 Fairchild Semiconductor Corporation
KSC5603D Rev. C2
1
www.fairchildsemi.com
