10A-ZMD
＆
10B-ZMD
Series
10W, WIDE INPUT, ISOLATED & REGULATED DUAL/SINGLE OUTPUT DC-DC CONVERTER
SELECTION GUIDE
Input
Output
Efficiency
Order code
Voltage(VDC)
Nominal
Range
Voltage
Max*
(VDC)
±3.3
±5
±12
±15
Current(mA)
(%,Typ)
Max.
±1515
±1000
±416
±333
Min.
±152
±100
±42
±33
FEATURES
◆
◆
◆
◆
◆
◆
◆
◆
◆
10A2403ZMD
10A2405ZMD
10A2412ZMD
10A2415ZMD
10B2403ZMD
10B2405ZMD
10B2412ZMD
10B2415ZMD
10A4812ZMD
10A4815ZMD
10B4812ZMD
24
24
24
24
24
24
24
24
48
48
48
48
9-36
9-36
9-36
9-36
9-36
9-36
9-36
9-36
18-72
18-72
18-72
18-72
40
40
40
40
40
40
40
40
80
80
80
80
83
84
81
83
81
79
81
81
85
83
85
83
Wide (4:1) Input Range
Short Circuit Protection(automatic recovery)
1500VDC Isolation
Operating Temperature: -40℃½﹢85℃
3.3
5
12
15
±12
±15
3030
2000
833
666
±416
±333
303
200
83
67
±42
±33
No heat sink required
No external component required
Internal SMD required
Metal shielding package
MTBF>1000Khours
12
15
833
666
83
67
MODEL SELECTION
10B 24 05 Z M D
①Product
Series
③Output
Voltage
⑤Metal
Shield
①
②
③
④
⑤
⑥
10B4815ZMD
*Input voltage can’t exceed this value,or will cause the permanent damage.
②Input
Voltage
④Wide
(4:1) Input Range
⑥DIP
Package Style
APPLICATIONS
The 10A-ZMD&10B-ZMD Series are specially
designed for applications where a wide range
input voltage power supplies are isolated from
the input power supply in a distributed power
supply system on a circuit board.
These products apply to:
1
）
Where the voltage of the input power
supply is wide range (Voltage range≤4:1);
2
）
Where isolation is necessary between
input and output (Isolation voltage≥1500VDC);
3）
Where the regulation of the Output voltage
and the output ripple noise are demanded.
COMMON SPECIFICATIONS
Parameter
Storage humidity
Operating temperature
Storage temperature
Temp. rise at full load
Lead temperature
Cooling
Short circuit protection
1.5mm from case for 10 seconds
Conditions
Min.
Typ.
Max.
95
Units
%
℃
℃
℃
-40
-55
40
85
125
300
Free Air Convection
℃
Continuous, Automatic recovery
Case material
Isolation voltage
Isolation resistance
Isolation Capacitance
MTBF
Tested for1 minute and 1mA max
Aluminum Alloy metal
1500
1000
1000
1000
23.5
VDC
MΩ
pF
K hours
Test at 500VDC
Input/output
MICRODC R ESERVES THE COPYRIGHT
Weight
g
http://www.microdc.cn
Technical Enquiries-Email:tech@microdc.cn Tel:0086-20-86000646
page 1/3
10A-ZMD
＆
10B-ZMD
Series
TEMPERATURE CHARACTERISTICS
Parameter
Output power
Positive voltage accuracy
Negative voltage accuracy
Load regulation
Line regulation
Temperature drift (Vout)
Ripple**
Noise**
Switching frequency
TYPICAL CHARACTERISTICS
Typ.
Max.
10
±1
±3
±0.5
±0.2
±3
±5
±1*
±0.5
±0.03
20
75
300
50
150
Conditions
See below products program
Refer to recommended circuit
Refer to recommended circuit
Form 10% to 100% load
Input voltage from low to high
Refer to recommended circuit
20MHz Bandwidth
20MHz Bandwidth
100% load, input voltage range
Min.
1.0
Units
W
%
%
%
%
%/°C
mVp-p
mVp-p
KHz
Temperature Derating Graph
RECOMMENDED CIRCUIT
* Dual output models unbalanced load: ±5%.
** Test ripple and noise by “parallel cable” method. See detailed
Testing of Power Converter section, application notes.
Output Graph
operation instructions at
Case material
APPLICATION NOTE
Requirement on output load
In order to ensure the product operate efficiently and reliably,in addition to a
max load(namely full load), a minimum load is specified for this kind of
DC/DC converter.Make sure the specified range of input voltage is not
exceeded,the minimum output load no less than 10% load.If the actual load
is less than the specified minimum load, the output ripple may increase
sharply while its efficiency and reliability will reduce greatly.If the actual
output power is very small,please add an appropriate resistor as extra
loading,or contact our company for other lower output power products.
Recommended Circuit
All the 10A_ZMD&10B_ZMD Series have been tested according to
the following recommended testing circuit before leaving factory.This series
should be tested under load(see Figure 1).
If you want to further decrease the input/output ripple,you can increase
capacitance properly or choose capacitors with low ESR.However,the
capacitance of the output filter capacitor must be proper.If the capacitance
is too big,a startup problem might arise.For every channel of output,provided
the safe and reliable operation is ensured,the greatest capacitance of its
filter capacitor sees (Table 1).General:
Cin: 10μF-47μF
Cout: 10μF/100mA
CTRL Terminal
When open or high impedance,the converter work well; When this pin is
‘high’; the converter shutdown; It should be note that the input current (Ic)
should between 5-10mA, exceeding the maximum 20mA will cause
permanence damage to the converter.
The value of R Can be derived as follows :
Input current
While using unstable power source,please ensure the output voltage and
ripple voltage do not exceed indexes of the converter.The preceding power
source must be able to provide for converter sufficient starting current
Ip(Figure 2).
General:Ip≤1.6*Iin-max
No parallel connection or plug and play
Output External Capacitor Table(Table 1)
Single
V
out
C
out
(μF)
Dual V
out
(VDC)
C
out
(μF)
(VDC)
5
12
15
680
470
330
±5
±12
±15
680
330
220
page 1/3
http://www.microdc.cn
Technical Enquiries-Email:tech@microdc.cn Tel:0086-20-86000646
10A-ZMD
＆
10B-ZMD
Series
OUTLINE DIMENSIONS
＆
FOOTPRINT DETAILS
MECHANICAL DIMENSIONS
RECOMMENDED FOOTPRINT
Note:
Unit:mm[inch]
Pin section tolerances:±0.10mm[±0.004inch]
General tolerances:±0.25mm[±0.010inch]
FOOTPRINT DETAILS
RECOMMENDED FOOTPRINT
Top view,grid:2.54mm[0.1inch]
diameter:1.00mm[0.039inch]
TUBE OUTLINE DIMENSIONS
Pin
1
2
3
4
5
Single
GND
Vin
+Vo
NP
0V
Dual
GND
Vin
+Vo
0V
-Vo
NP:No Pin
When the environment temperature is higher than 71℃,
the product output power should be less then 60% of
the rated power.
No parallel connection or plug and play.
Use dual output simultaneously,forbid pening output
pin (0V) to use as single output.
Note:
1. The load shouldn't be less than 10%, otherwise ripple will increase dramatically.
2. Operation under 10% load will not damage the converter; However, they may not meet all specification listed.
3. All specifications measured at Ta=25°C, humidity<75%, nominal input voltage and rated output load unless otherwise specified.
4. In this datasheet, all the test methods of indications are based on corporate standards.
5. Only typical models listed, other models may be different, please contact our technical person for more details.
http://www.microdc.cn
Technical Enquiries-Email:tech@microdc.cn Tel:0086-20-86000646
page 1/3
