SHEET 1 OF 1
(X) DIM
5.00
[.197 in]
[.906 in]
n
23.00
20.80
[.819 in]
n
20.00
[.787 in]
2.10
[.083 in]
PANEL CUTOUT
PANEL THICKNESS
0.75 TO 1.25
1.25 TO 2.00
2.00 TO 3.00
SWITCH FUNCTION
POS. 1
POS. 2
(X) DIM.
20.2mm
20.4mm
20.6mm
5.50
`
.50
[.217
`
.020
in]
POS. 2
POS. 1
ACUATOR COLOR:
BLACK
2.00
[.079 in]
20.70
[.815 in]
OFF
OPEN
ON
1-1a
1
1a
CIRCUIT: SPST
BODY COLOR:
BLACK
14.50
[.571 in]
22.50
`
.50
[.886
`
.020
in]
NOTE:
1. DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X =
±
0.4
X.XX =
±
0.25
3. TERMINAL NUMBERS FOR REF ONLY
4. CONTACT MATERIAL: SILVER
5. CONTACT RATING: 10A @ 125VAC [UR, cUR]
6(2)A @ 250V~ µ 1E4 T125/55 [ENEC14, SEMKO]
6. CONTACT RESISTANCE: 35mΩ MAX. @ 50VAC
7. INSULATION RESISTANCE: 100MΩ MIN. @ 500VAC
8. DIELECTRIC STRENGTH: 1,500VAC FOR 1 MINUTE
9. ELECTRICAL LIFE: 6,000 CYCLES [UR, cUR]
10,000 CYCLES [ENEC14, SEMKO: 10(4)A 250V~]
10. OPERATING TEMPERATURE: -20°C TO 105°C [UR, cUR]
-20°C TO 125°C [ENEC14, SEMKO]
11. DENOTES CRITICAL PARAMETER
12. 2002/95/EC (ROHS) COMPLIANT
B
A
REV
20518
20393
PCR NO
Changed outer diameter from 25 to 23
RELEASE FOR PRODUCTION
DESCRIPTION
3/7/2012
1/10/12
DATE
MM
1
1a
.80
[.031 in]
1
1a
4.75
[.187 in]
9.20
[.362 in]
2.50
[.098 in]
4.00
[.157 in]
BGL
BY
TITLE
SCALE
RR81131100
DATE
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
2:1
1/10/2012
BGL
DR
38-RR81131100
DWG
REV
B
