SHEET 1 OF 1
(X) DIM
n
23.00
5.00
[.197 in]
[.906 in]
20.80
[.819 in]
n
20.00
SWITCH FUNCTION
POS. 1
POS. 2
2.10
[.083 in]
PANEL CUTOUT
PANEL THICKNESS
0.75 TO 1.25
1.25 TO 2.00
2.00 TO 3.00
[.787 in]
(X) DIM.
20.2mm
20.4mm
20.6mm
OFF
OPEN
ON
1-1a
2-2a
5.50
`
.50
[.217
`
.020
in]
POS. 2
POS. 1
ACUATOR COLOR:
BLACK
1
2
2.00
[.079 in]
20.70
[.815 in]
1a
2a
BODY COLOR:
BLACK
14.50
[.571 in]
22.50
`
.50
[.886
`
.020
in]
CIRCUIT: DPST
OFF-ON
NOTE:
1. DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X =
±
0.4
X.XX =
±
0.25
3. TERMINAL NUMBERS FOR REF ONLY
4. CONTACT MATERIAL: SILVER
5. CONTACT RATING: 16A 125VAC [UL, cUL]
10A 250VAC [UL, cUL]
1/3HP 125/250VAC [UL, cUL]
10(4)A 250V~1E4 T125/55 [VDE]
10(2)A 250V~5E4 T185/55 [VDE]
6. CONTACT RESISTANCE: 35m MAX. @ 50VAC
7. INSULATION RESISTANCE: 100M MIN. @ 500VAC
8. DIELECTRIC STRENGTH: 1,500VAC FOR 1 MINUTE
9. ELECTRICAL LIFE: 6,000 CYCLES [UR, cUR]
10,000 CYCLES [ENEC14, SEMKO: 10(4)A 250V~]
10. OPERATING TEMPERATURE: -20°C TO 105°C [UR, cUR]
-20°C TO 125°C [ENEC14, SEMKO]
11. DENOTES CRITICAL PARAMETER
12. 2002/95/EC (ROHS) COMPLIANT
D
C
REV
21393
20525
PCR NO
CORRECT SCHEMATIC
CONVERTED TO INVENTOR
DESCRIPTION
3/4/14
3/8/2012
DATE
1
1a
.80
[.031 in]
1
1a 2a
2
4.75
[.187 in]
9.20
[.362 in]
2.50
[.098 in]
4.00
[.157 in]
EBP
MM
BY
TITLE
38-RR812C1100
DATE
DR
DWG
REV
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
SCALE
2:1
3/8/2012
BGL
38-RR812C1100
D
