Global Connector Technology Ltd. - BD026: 1.27mm Pitch Elevated Shrouded Pin Header, Dual Row, Through Hole, Vertical
A
1.27 (Typ.)
B±0.38
A±0.25
3.37
1.27
Typ (Non-Accum)
5
6
7
8
A
3.92
Ø0.85 (Typ.)
5
.6
. )
Ø0
Typ
(
B
1.27
2.10
F±0.20
B
1.27
Recommended PCB Layout
1.84
C
2.20
5.65
C
H
1.00
1.50
D
D±0.2
D
Ø0.70 (Typ)
E
E±0.2
PIN 0.40 SQ (Typ)
2.00
C±0.20
E
Ordering Grid
BD026
F
Specifications
规格
:
XX
X
X
X
XXXX
XXXX
L
X
REQUEST SAMPLES
AND QUOTATION
G
Current Rating
电流额定值
: 1 Amp.
Insulator Resistance
绝缘电阻值
: 1000 MΩ min.
Dielectric Withstanding
耐电压
: AC 300 V
Contact Resistance
接触电阻值：
20 mΩ max.
Operating Temperature
工½温度
: -40°C TO +105°C
Contact Material
端子物料
: Copper Alloy
Insulator Height 'H'
Insulator Material
绝缘½物料
: Polyester
聚酯,
LCP, UL 94V-0
S = 5.70mm
(Standard)
Soldering Process
可焊性
:
U = 15.90mm
IR Reflow
回流焊
: 260°C for 10 sec.
Wave
波峰焊
: 250°C for 5-10 sec
Manual Solder
人工焊接
: 350°C for 3-5 sec
Mates with
配套之母座
(Subject to pin length
在端子长度适合的条件下
):
BD065 - Allowing perfect polarisation
- Non-Polarised mating connections available - contact GCT for details
No. of Contacts
10 to 80
Contact Plating
A = Gold Flash All Over
(Standard)
B = Selective Gold Flash Contact Area/
Tin On Tail
C = Tin All Over
G = 10µ" Gold Contact Area/Tin On Tail
I = 30µ" Gold Contact Area/Tin On Tail
Packing Options
D = Tube
(Standard)
G = Plastic Box
Insulator Material
L = LCP
Dimension E (Tail Length)
(1/100mm)
0300 = 3.00mm
(Standard)
or specify Dimension E
eg 0250 = 2.50mm
Dimension D (Stack Height)
(1/100mm)
1790 = 17.90mm
(Standard)
or specify Dimension D
eg 0250 = 2.50mm
Tolerances
(Except as noted)
F
G
Locating Peg
0 = Without
1 = With
Part Number:-
Date:-
Dimensions in mm
X. ± 0.30
X.X ± 0.20
X.XX ± 0.15
X.XXX ± 0.10
BD026
30 Mar '08
H
By
REV
DATE
AJO
B1
28/05/14
1
2
3
4
X.°±5°
Description:-
.X°±2°
1.27mm Pitch Elevated Shrouded Pin Header,
.XX°±1°
Dual Row, Through Hole, Vertical
.XXX°±0.5°
THIS DRAWING IS CONFIDENTIAL AND MUST NOT BE
COPIED OR DISCLOSED WITHOUT WRITTEN CONSENT
Third Angle Projection
GC
Scale
NTS
H
Sheet No.
E & OE
1/1
www.gct.co
Material
See Note
C
Revision
B1
Drawn by
AE
5
6
7
8
