SHEET 1 OF 1
SWITCH FUNCTION
(X)
5.00
[.197 in]
20.40
[.803 in]
ON
2-3
13.50
[.531 in]
PANEL THICKNESS (X) DIMENSION
0.75 TO 1.25
23.3
1.25 TO 2.00
23.6
2.00 TO 3.00
23.9
SUGGESTED PANEL CUTOUT
BLACK ACTUATOR
2.00
[.079 in]
NOTE:
1. ALL DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X = ± 0.4
BLACK BODY
X.XX = ± 0.25
3. TERMINAL NOS. FOR REF. ONLY
4. RATINGS: ANSI/UL 1054:
10A 125VAC [UR, cUR]
6(2)A 250V~ µ 5E4 T85 [ENEC14, SEMKO]
18.60
`
.50
[.732
`
.020
in]
5. CONTACT MATERIAL: SILVER ALLOY CLAD COPPER
6. CONTACT RESISTANCE: 35mΩ MAX. @ 50VAC INITIAL
7. INSULATION RESISTANCE: 100MΩ MIN. @ 500VDC
8. DIELECTRIC STRENGTH: 1,500 VAC FOR 1 MINUTE
9. ELECTRICAL LIFE: 10,000 CYCLES
10. TEMPERATURE: -20°C TO 105°C [UR, cUR]
.80
-20°C TO 125°C [ENEC14, SEMKO: 10(2)A 250V~]
[.031 in]
11.
DENOTES CIRTICAL PARAMETER
12. 2002/95/EC (ROHS) COMPLIANT
POS. 1
1
3
OFF
OPEN
ON
2-1
POS. 1
POS. 2
POS. 3
25.60
[1.008 in]
17.50
[.689 in]
2
CURCUIT: SPDT
S MARKING
COLOR: WHITE
POS. 3
6.00
`
.50
[.236
`
.020
in]
13.50
[.531 in]
1
2
7.00
[.276 in]
3
3
3.20
[.126 in]
21.50
[.846 in]
13.40
[.528 in]
A
REV
21070
PCR NO
RELEASE FOR PRODUCTION
DESCRIPTION
3/15/13
DATE
EBP
BY
TITLE
RE1553112S
DATE
DR
DWG
REV
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
SCALE
3/15/2013
EBP
38-RE1553112S
A
