Super Flux 4in1 Pure White
LED
OSW4G4Z2C1P
■
Features
●
■
Outline
7.62
Dimension
Higher Luminous Output
5φStandard Directivity
Superior Weather-resistance
Long Lifetime Operation
Water Clear Type
7.62
●
●
5C
1.
1,4
2,3
Unit:mm
Tolerance:+0.3mm
1,4 Anode
2,3 Cathode
5.0
●
●
■
Applications
●
2.5
Electronic Signs And Signals
Illuminations
Reading Lamps / Emergency Lighting
Other Lighting
0.76+0.1
1.5+0.1
5.08+0.2
●
●
5.15
2.5
●
5.08+0.3
2
■
Absolute
2
3
Maximum Rating
Item
Symbol
I
F
I
FP
V
R
P
D
Topr
Tstg
Tsol
(Ta=25℃)
Value
20
40
5
272
-30 ~ +85
-40 ~ +100
260℃/5sec
■
Directivity
Unit
mA
mA
V
mW
℃
℃
-
0
DC Forward Current
Pulse Forward Current*
Reverse Voltage
Power Dissipation
Operating Temperature
Storage Temperature
Lead Soldering Temperature
0
*Pulse width Max 10ms , Duty ratio max 1/10
■
Electrical
-Optical Characteristics
Symbol
V
F
I
R
Φv
CCT
x
y
2θ
1/2
(Ta=25℃)
Min.
11.6
-
28
-
-
-
-
Item
DC Forward Voltage
DC Reverse Current
Luminous Flux
Color Temperature
Chromaticity
Coordinate*2
50% Power Angle
Condition
I
F
=20mA
V
R
=5V
I
F
=20mA
I
F
=20mA
I
F
=20mA
I
F
=20mA
I
F
=20mA
Typ.
12.0
-
30
6500
0.31
0.33
120
Max.
13.6
10
-
-
-
-
-
Unit
V
µA
lm
K
deg
*
1
Tolerance of chromaticity coordinates +10%
*
2
Tolerance of luminous flux is +15%
LED & Application Technologies
5.0+0.2
VER A.0
