SHEET 1 OF 1
(X)
SWITCH FUNCTION
POS. 1
13.00
[.512 in]
OFF
OPEN
PANEL CUTOUT
ON
1-1a
15.00
[.591 in]
POS. 2
21.00
[.827 in]
PANEL THICKNESS
0.75 - 1.25
1.25 - 2.00
2.00 - 3.00
(X) DIMENSION
19.2
19.4
19.6
BLACK ACTUATOR
6.00
`
.50
[.236
`
.020
in]
POS. 2
POS. 1
BLACK BODY
9.70
[.382 in]
1
1a
CIRCUIT: SPST
NOTE:
1. DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X =
±
0.4
2.00
[.079 in]
X.XX =
±
0.25
3. TERMINAL NUMBERS FOR REF ONLY
17.40
`
.50
4. CONTACT MATERIAL: SILVER
[.685
`
.020
in]
5. CONTACT RATINGS: 10A 125VAC
UL 1054 AND CAN/CSA C22.2 NO. 55 (E194579):
10A @ 125VAC [UR, cUR]
EN 61058-1:2002
6(2)A 250V~ 1E4 T85 ENEC
6. CONTACT RESISTANCE: 35mΩ MAX. @ 50VAC
7. INSULATION RESISTANCE: 100MΩ MIN. @ 500VAC
7.00
8. DIELECTRIC STRENGTH: 1,500VAC FOR 1 MINUTE
[.276 in]
9. ELECTRICAL LIFE: 6,000 CYCLES [UR, cUR]
10,000 CYCLES [ENEC14, SEMKO: 10(4)a 250V~]
50,000 CYCLES [ENEC14, SEMKO: 10(2)a 250v~]
10. OPERATING TEMPERATURE: -20°C TO 105°C [UR, cUR]
-20°C TO 125°C [ENEC14, SEMKO: 10(4)a 250v~]
-20°C TO 85°C [ENEC14, SEMKO: 10(2)a 250v~]
11. DENOTES CRITICAL PARAMETER
12. 2002/95/EC (ROHS) COMPLIANT
12.60
[.496 in]
2.30
[.091 in]
1a
1
.80
[.031 in]
1
3.10
[.122 in]
12.00
[.472 in]
12.90
[.508 in]
18.50
[.728 in]
A
REV
20567
PCR NO
INITIAL RELEASE
DESCRIPTION
05/17/12
DATE
drg
BY
TITLE
RA12131123
DATE
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
5/16/2012
DR
DWG
REV
drg
38-RA12131123
A
