38-RA12431200: DescriptionALL DIMENSIONS IN MM [INCH]; File Size90KB，1 Pages; ManufacturerE-Switch; Websitehttp://www.e-switch.com

Download Datasheet View All

38-RA12431200 Overview

ALL DIMENSIONS IN MM [INCH]

Preview

Download Datasheet

View All

SHEET 1 OF 1

(X)

SWITCH FUNCTION

POS. 1

13.00

[.512 in]

OFF

OPEN

PANEL CUTOUT

PANEL THICKNESS

0.75 - 1.25

1.25 - 2.00

2.00 - 3.00

(X) DIMENSION

19.2

19.4

19.6

POS. 2

21.00

[.827 in]

(ON)

1-1a

15.00

[.591 in]

(ON) = MOMENTARY

WHITE ACTUATOR

6.00

.50

[.236

.020

in]

POS. 2

POS. 1

BLACK BODY

9.70

[.382 in]

CIRCUIT: SPST

NOTE:

1. DIMENSIONS IN MM [INCH]

2. GENERAL TOLERANCE: X.X =

0.4

2.00

X.XX =

0.25

[.079 in]

3. TERMINAL NUMBERS FOR REF ONLY

4. CONTACT MATERIAL: SILVER

5. CONTACT RATINGS:

17.40

.50

ANSI/UL 1054 AND CAN/CSA C22.2 NO. 55 (E194579): [.685

.020

in]

10A @ 125VAC [UR, cUR]

EN 61058-1:2002:

6(2)A 250V~

1E4 T125/55 [ENEC14, SEMKO]

6. CONTACT RESISTANCE: 35mΩ MAX. @ 50VAC

7. INSULATION RESISTANCE: 100MΩ MIN. @ 500VAC

8. DIELECTRIC STRENGTH: 1,500VAC FOR 1 MINUTE

.80

9. ELECTRICAL LIFE: 6,000 CYCLES [UR, cUR]

[.031 in]

10,000 CYCLES [ENEC14, SEMKO]

10. OPERATING TEMPERATURE: -20°C TO 105°C [UR, cUR]

7.00

[.276 in]

-20°C TO 125°C [ENEC14, SEMKO]

11. DENOTES CRITICAL PARAMETER

12. 2002/95/EC (ROHS) COMPLIANT

11.60

[.457 in]

2.30

[.091 in]

3.10

[.122 in]

12.00

[.472 in]

18.90

[.744 in]

12.90

[.508 in]

REV

20436

PCR NO

RELEASE FOR PRODUCTION

DESCRIPTION

1/30/12

DATE

BGL

TITLE

SCALE

RA12431200

2:1

DATE

THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY

TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED

1/30/2012

BGL

38-RA12431200

DWG

REV
