14-RSC441D1000136

Description
Silver Plated Copper
File Size151KB,1 Pages
ManufacturerE-Switch
Websitehttp://www.e-switch.com
Download Datasheet View All

14-RSC441D1000136 Overview

Silver Plated Copper

SHEET 1 OF 1
[
.476
12.10
- .10
.00
+.004
- .000
+
in
]
3
2
1
3
2
1
POS. 1
CIRCUIT: SPST
OFF - ON
POS. 2
31.50
[1.240 in]
[
1.126
28.60
- .10
.00
+.004
- .000
+
in
]
SUGGESTED PANEL CUTOUT
16.70
[.657 in]
9.5
[.37 in]
GREEN ACTUATOR
(FULL ILLUMINATION)
POS.
1
POS.
2
7.8
[.31 in]
BLACK
HOUSING
2.00
[.079 in]
18.50
[.728 in]
28.0
[1.10 in]
n
1.70
1
6.90
[.272 in]
2
3
[.067 in]
6.30
[.248 in]
12.00
[.472 in]
24.00
[.945 in]
28.50
[1.122 in]
NOTES:
1. ALL DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X=±0.4
X.XX=±0.25
3. TERM. NOS. FOR REF. ONLY
4. RATING: 20A 125/250VAC (UL/CUL)
16(4) 250V~T85/55 (VDE/ENEC)
20(8)A 250X~ T125/55
5. MATERIAL:
CONTACT SURFACE: SILVER PLATED COPPER
CIRCUIT TERMINAL: BRASS ALLOY w/SILVER PLATE
LED TERMINAL: BRASS
.80
6. ELECTRICAL LIFE: 10,000 CYCLES MIN.
[.031 in] 7. CONTACT RESISTANCE: 20 Milli-OHMS MAX.
8. OPERATING TEMP: -20°C TO 85°C
9. DIELECTRIC STRENGTH: >1,000V AC 1MIN
10. LAMP VOLTAGE: 125V NEON BULB
11. DENOTES CRITICAL PARAMETER.
12. 2002/95/EC (ROHS) COMPLIANT.
A
REV
21495
PCR NO
INITIAL RELEASE
DESCRIPTION
6/26/14
DATE
EBP
BY
TITLE
RSC441D1000-136
DATE
DR
DWG
REV
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
SCALE
6/26/2014
EBP
14-RSC441D1000136
A
