Y100012 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Y100012

Preview

Y100012: DescriptionALL DIMENSIONS IN MM [INCH]; File Size202KB，1 Pages; ManufacturerE-Switch; Websitehttp://www.e-switch.com

Download Datasheet View All

Y100012 Overview

ALL DIMENSIONS IN MM [INCH]

Preview

Download Datasheet

View All

SHEET 1 OF 1

SWITCH FUNCTION

POS. 1

POS. 2

[

.878

RECOMMENDED PANEL MOUNTING

22.30

- .10

.00

+.004

- .000

]

MARKING COLOR

WHITE

25.00

[.984 in]

OFF

OPEN

2-1, 5-4

25.00

[.984 in]

PANEL THICKNESS

29.9/30.0

30.3/30.4

30.7/30.8

32.00

[1.260 in]

1.2-1.8

1.8-2.4

2.4-3.0

CIRCUIT: SPDT

FUNCTIONS

GREEN FULL

ILLUMINATED

ROCKER

RUBBER GASKET

(Y000100)

POS

8.80

.50

[.346

.020

in]

RUBBER PLUG

BOTH SIDES

19.00

[.748 in]

NOTES:

1. ALL DIMENSIONS IN MM [INCH]

2. GENERAL TOLERANCE: X.X=±0.4

X.XX=±0.25

3. TERM. NOS. FOR REF. ONLY

4. RATING: CUL: 16(16)A 125VAC 5E4 T85

1/3HP 125VAC IP66

VDE: 10(10)A 250VAC 5E4 T85

5. MECHANICAL LIFE: 50,000 CYCLES

6. CONTACT RESISTANCE: <30 MILLI-OHMS INITIAL

7. DIELECTRIC STRENGTH: 1000V AC 1MIN

8. DENOTES CRITICAL PARAMETER.

9. INSULATION RESISTANCE: 500M OHMS AT 500VDC

10. OPERATING TEMP: -20°C to 85°C

11. LAMP: 250VAC NEON

12. RATING: IP66

13. 2002/95/EC (ROHS) COMPLIANT

2.00

[.079 in]

BLACK

HOUSING

11.00

[.433 in]

27.00

[1.063 in]

28.00

[1.102 in]

32.00

[1.260 in]

29.30

[1.154 in]

10.00

[.394 in]

.80

[.031 in]

21.50

[.846 in]

22.10

[.870 in]

6.30

[.248 in]

11.00

[.433 in]

REV

20086

20078

PCR NO

ADD RUBBER GASKET

New Release

DESCRIPTION

8/5/11

8/4/11

DATE

BGL

TITLE

SCALE

RBW2ABLKGILFF2

2:1

DATE

THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY

TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED

8/4/2011

BGL

DWG

Y100012

REV
