3.3V TRI-STATE ENABLE/DISABLE OSCILLATORS
MODEL: H5C-2E3
FEATURES
•
•
•
•
3.3V Operation
HCMOS Output
Tri-State Enable/Disable
8-Pin DIP
OPTIONS
• 14-Pin DIP Available (F5C-2E3)
Discontinued
Learn more about:
Part Marking Identification
Mechanical Specification
Internet required
• PART NUMBER SELECTION
Learn More - Internet Required
Part Number
350-Frequency-xxxxx
351-Frequency-xxxxx
272-Frequency-xxxxx
352-Frequency-xxxxx
354-Frequency-xxxxx
353-Frequency-xxxxx
566-Frequency-xxxxx
Model
Number
H5C-2E3
H5C-2E3R
H6C-2E3
H6C-2E3R
H7C-2E3
H7C-2E3R
H8C-2E3
Frequency
Operating
1
Stability
Temperature (ºC)
±100PPM
0 ~ +70
±100PPM
-40 ~ +85
±50PPM
0 ~ +70
±50PPM
-40 ~ +85
±25PPM
0 ~ +70
±25PPM
-40 ~ +85
±20PPM
0 ~ +70
Frequency
Range (MHz)
1.000~160.000
1.000~160.000
1.000~160.000
1.000~160.000
1.000~160.000
1.000~125.000
1.000~125.000
• ELECTRICAL CHARACTERISTICS
PARAMETERS
Frequency Range (F
O
)
Storage Temperature Range (T
STG
)
Supply Voltage
(V
DD
)
Input Current
(I
DD
)
1.000 ~ 23.999 MHz
24.000 ~ 49.999 MHz
50.000 ~ 69.999 MHz
70.000 ~ 125.000 MHz
125.000 ~ 160.000 MHz
Output Symmetry (50% V
DD
)
Rise Time (10% ~ 90% V
DD
) (T
R
)
Fall Time (90% ~ 10% V
DD
) (T
F
)
Output Voltage
(V
OL
)
(V
OH
)
Output Current
(I
OL
)
(I
OH
)
Output Load
(HCMOS)
Start-up Time
(T
S
)
Output Enable/Disable Time
2
1
MAX
(unless otherwise noted)
1.000 ~ 160.000 MHz
-55ºC ~ +125ºC
3.3V ± 10%
15mA
20mA
40mA
45mA
60mA
40% ~ 60%
10 nS
10 nS
10% V
DD
90% V
DD
Min
8mA Min
-8mA Min
15pF
10mS
100nS
Inclusive of 25ºC tolerance, operating temperature range, input voltage change, load change, aging,
shock, and vibration.
2
An internal pullup resistor from pin 1 to V
DD
allows active output if pin 1 is left open.
All specifications subject to change without notice.
Rev. 6/1/04
All dimensions are in millimeters.
• ENABLE / DISABLE FUNCTION
INH (Pin 1)
OUTPUT (Pin 5)
OPEN
2
ACTIVE
'1' Level V
IH
≥
2.2 V
ACTIVE
'0' Level V
IL
≤
0.8 V
High Z
64
FOXElectronics
5570 Enterprise Parkway Fort Myers, Florida 33905 USA +1(239)693-0099 FAX +1(239)693-1554
http://www.foxonline.com
© 2004 FOX ELECTRONICS
