569107-1 Product Details
Live Product Chat
Product Photo
PCB Mounted Jacks - Single Port, Multi-port and Stacked
5 of 6 EU R oHS/ELV C om plia nt
(
Find R oHS C om plia nt
Alte rna te s
/
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
569107-1
T E I nternal N umber: 5 6 9 1 0 7 - 1
Product Highlights:
l
Jack
l
Single Port C onfiguration
l
1 x 1 Jack C onfiguration
l
Jack Type = RJ45
l
Number of Positions = 8
View all Features
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Superseded
Search for Replacement Parts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
High Performance Modular Plugs & Jacks, PC B Mounted
(PDF, English)
Application Specifications:
l
Modular Jacks
(PDF, English)
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= Jack
l
Jack Type
= RJ45
l
Number of Positions
= 8
l
PC B Mount Angle
= Side Entry (Right Angle)
l
PC B Mount Style
= Through Hole
l
PC B Termination Type
= Solder
l
Shielded
= No
l
Performance C ategory
= C at 5
l
Number of C ontacts Loaded = 8
l
Grounding Options = Without
l
Panel Stops
= With
l
Keyed
= Yes
l
Profile
= Standard
l
C olor
= Black
l
Latch Style = Standard
l
PC B Thickness (mm [in]) = 1.57 [0.062]
Mechanical Attachment:
l
Jack C onfiguration
= 1 x 1
l
Panel Attachment
= With
l
Flanged = No
Termination Related Features:
l
Height (mm [in])
= 13.39 [0.527]
l
Solder Tail C ontact Plating
= Tin-Lead over Nickel
Body Related Features:
l
Port C onfiguration = Single
l
Inverted Jack Face
= No
l
LED
= Without
l
PC B Tail Length (mm [in])
= 3.56 [0.140]
Contact Related Features:
l
C ontact Mating Area Plating Material
= Gold (50)
l
C ontact Base Material = Phosphor Bronze
Housing Related Features:
l
Housing Material = High Temperature Nylon
l
Housing Flammability Rating = UL 94V-0
Industry Standards:
l
RoHS/ELV C ompliance
= ELV compliant, 5 of 6 C ompliant
l
Lead Free Solder Processes
= Wave solder capable to 240?C
Packaging Related Features:
l
Packaging Method = Tray
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
Additional Product Images:
l
Solder Tail Sequence
