F3345-10.000MHZ

Description
CRYSTAL OSCILLATOR, CLOCK, 16 MHz, HCMOS OUTPUT
Categorysemiconductor    Analog mixed-signal IC
File Size368KB,3 Pages
ManufacturerFOX [Fox Electronics]
Download Datasheet Parametric View All

F3345-10.000MHZ Overview

CRYSTAL OSCILLATOR, CLOCK, 16 MHz, HCMOS OUTPUT

F3345-10.000MHZ Parametric

Parameter NameAttribute value
Maximum operating temperature70 Cel
Minimum operating temperature-10 Cel
Rated supply voltage5 V
Rated operating frequency16 MHz
Lead-freeYes
EU RoHS regulationsYes
China RoHS regulationsYes
stateACTIVE
terminal coatingGOLD
Installation featuresTHROUGH HOLE MOUNT
Frequency converter0
Manufacturer SeriesF3345
Vibration typeHCMOS
5.0V, HCMoS, SMD oscillator
Page 1 of 2
Model: F3345 SERIES
RoHS Compliant / Pb Free
http://www.foxonline.com/need_a_sample.htm
Rev. 1/29/2014
FEATURES
5.0V Operation
HCMOS/TTL Output
Tri-State Enable/Disable
Tape and Reel
(2,000 pcs. STD)
oPTIonS
• Standby Function (F4101)
• PART nUMbER SELECTIon
Part Number
092-Frequency-xxxxx
093-Frequency-xxxxx
090-Frequency-xxxxx
091-Frequency-xxxxx
094-Frequency-xxxxx
095-Frequency-xxxxx
096-Frequency-xxxxx
Operating
Model Frequency
Number Stability
1
Temperature (ºC)
F3345
±100PPM
-10 ~ +70
F3345R
±100PPM
-40 ~ +85
F3340
±50PPM
-10 ~ +70
F3340R
±50PPM
-40 ~ +85
F3346
±25PPM
-10 ~ +70
F3346R
±25PPM*
-40 ~ +85
F3348
±20PPM*
-10 ~ +70
Frequency
Range (MHz)
1.000 ~ 80.000
1.000 ~ 80.000
1.000 ~ 80.000
1.000 ~ 80.000
1.000 ~ 80.000
1.000 ~ 80.000
1.000 ~ 80.000
7.5 Max
Top
View
#4
#1
#3
5.2 Max
#2
Dot denotes
pin 1
1.5 Max
1.4±0.2
Bottom
View
• ELECTRICAL CHARACTERISTICS
PARAMETERS
Frequency Range (F
o
)
Storage Temperature Range (T
stg
)
Supply Voltage
(V
dd
)
Input Current
(I
dd
)
1.000 ~ 25.000 MHz
25.000+ ~ 50.000 MHz
50.000+ ~ 67.000 MHz
67.000+ ~ 80.000 MHz
Output Symmetry (50% V
dd
)
Rise Time (10% ~ 90% V
dd
) (T
r
)
Fall Time (90% ~ 10% V
dd
) (T
f
)
Output Voltage
(V
ol
)
(V
oh
)
Output Current
(I
ol
)
(I
oh
)
Output Load
TTL
HCMOS
Start-up Time
(T
s
)
Enable/Disable Time
2
Maximum Soldering Temp / Time
Moisture Sensitivity Level (MSL)
Termination Finish
1
MAX
(unless otherwise noted)
1.000 ~ 80.000 MHz
-55ºC ~ +125ºC
5.0V ± 10%
25mA
40mA
60mA
73mA
45% ~ 55%
7nS
7nS
10% V
dd
90% V
dd
Min
16mA Min
-16mA Min
10TTL
50pF
10mS
100nS
260ºC / 10 Seconds
1
Au
#1
#4
#2
#3
5.08±0.1
2.6±0.2
Recommended
Solder Pad Layout
1.8±0.1
2.0±0.1
4.2±0.1
5.08±0.1
Pin Connections
#1 E/D #3 output
#2 GnD #4 V
DD
All dimensions are in millimeters
Inclusive of 25ºC tolerance, operating temperature range, input voltage change, load change, aging,
shock, and vibration. *Excludes Shock/Vibration
2
An internal pullup resistor from pin 1 to pin 4 allows active output if pin 1 is left open.
Note: A 0.01µF bypass capacitor should be placed between VDD (Pin 4) and GND (Pin 2) to
minimize power supply line noise.
Drawing is for reference to critical specifications defined by size measurements.
Certain non-critical visual attributes, such as side castellations, reference pin shape, etc. may
vary. All specifications subject to change without notice.
• EnAbLE / DISAbLE FUnCTIon
OUTPUT (Pin 3)
INH (Pin 1)
ACTIVE
OPEN
2
ACTIVE
'1' Level V
ih
70% V
dd
High Z
'0' Level V
il
30% V
dd
USA +1.239.693.0099
FOXonline.com
FAX +1.239.693.1554
Fox Electronics
5570 Enterprise Parkway
Fort Myers, Florida 33905
An Integrated Device Technology, Inc. company
