PND
CONNECTOR
2.0mm pitch/Disconnectable Crimp style connectors
Specifications –––––––––––––––––––
• Current rating: 3A AC, DC (AWG #22)
• Voltage rating: 250V AC, DC
• Temperature range:
-
25˚C to
+
85˚C
(including temperature rise in applying
electrical current)
• Contact resistance: Initial value/ 10m
Ω
max.
After environmental testing/ 20m
Ω
max.
• Insulation resistance: 1,000M
Ω
min.
• Withstanding voltage: 800V AC/minute
• Applicable wire: AWG #28 to #22
* Compliant with RoHS.
* Refer to "General Instruction and Notice when using Terminals
and Connectors" at the end of this catalog.
* Contact JST for details.
The PND connector is the high-density
dipping type connector with secure lock
for wire to board connection and enabled
to achieve excellent workability and
withstand the unexpected external force.
• Superior operability (Low insertion force)
• Withstanding external force and secure
locking device
• Countermeasure for inverse insertion and
mismatching insertion
• High density
• Polarizing boss
Standards ––––––––––––––––––––––
1
0
Recognized E60389
Certified LR20812
1.45
±0.05
φ1
±0.05
＋0.1
0
A
±0.05
2
±0.05
11.7
（3.6）
5
±0.05
（10.7）
1.55
φ0.7
＋0.1
0
（2）
Connector outline
（B）
Note: 1. The above figure is the figure viewed from the connector mounting side.
2. Tolerances are non-cumulative:
±
0.05mm for all centers.
3. Hole dimensions differ according to the kind of PC board and piercing method. The dimensions above should serve as a guideline. Contact JST for details.
Contact
Model No.
SPND-001T-C0.5
SPND-002T-C0.5
7.5
3
3.9
1.5
12.9
Applicable wire
mm
2
AWG #
0.13∼0.33
0.08∼0.22
26∼22
28∼24
Insulation O.D.
(mm)
1.0∼1.5
0.8∼1.5
Q'ty /
reel
8,000
Material and Finish
Copper alloy, tin-plated (reflow treatment)
RoHS compliance
2.08
Contact
SPND- 001T-C0.5
Crimping
machine Crimp applicator
MKS-L
AP-K2N
−
MKS-L
−
Applicator
Dies
−
Crimp applicator with dies
−
MK/SPND-001-05 APLMK SPND001-05
SPND-002T-C0.5
MK/SPAD/ND-002-05 APLMK SPAD/ND002-05
−
−
1
PND CONNECTOR
Housing
Circuits
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
Model No.
PNDP-08V-Z
PNDP-10V-Z
PNDP-12V-Z
PNDP-14V-Z
PNDP-16V-Z
PNDP-18V-Z
PNDP-20V-Z
PNDP-22V-Z
PNDP-24V-Z
PNDP-26V-Z
PNDP-28V-Z
PNDP-30V-Z
PNDP-32V-Z
PNDP-34V-Z
PNDP-36V-Z
PNDP-38V-Z
PNDP-40V-Z
Dimensions (mm)
A
6.0
8.0
10.0
12.0
14.0
16.0
18.0
20.0
22.0
24.0
26.0
28.0
30.0
32.0
34.0
36.0
38.0
B
10.0
12.0
14.0
16.0
18.0
20.0
22.0
24.0
26.0
28.0
30.0
32.0
34.0
36.0
38.0
40.0
42.0
Q'ty / bag
500
500
500
500
300
300
300
300
250
250
250
150
150
150
100
100
100
B
11.7
2
A
5
11
Material
PA 66, UL94V- 0, ivory
RoHS compliance
<For reference>
As the color identification,
the following alphabet shall be put in the underlined part.
For availability, delivery and minimum order quantity, contact JST.
ex.
PNDP-28V-Z-
Z…ivory K…black R…red E…blue M…green N…brown
PK…pink D…orange
Shrouded header
Circuits
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
Model No.
With boss
B08B-PNDZS-1
B10B-PNDZS-1
B12B-PNDZS-1
B14B-PNDZS-1
B16B-PNDZS-1
B18B-PNDZS-1
B20B-PNDZS-1
B22B-PNDZS-1
B24B-PNDZS-1
B26B-PNDZS-1
B28B-PNDZS-1
B30B-PNDZS-1
B32B-PNDZS-1
B34B-PNDZS-1
B36B-PNDZS-1
B38B-PNDZS-1
B40B-PNDZS-1
Without boss
B08B-PNDZS
B10B-PNDZS
B12B-PNDZS
B14B-PNDZS
B16B-PNDZS
B18B-PNDZS
B20B-PNDZS
B22B-PNDZS
B24B-PNDZS
B26B-PNDZS
B28B-PNDZS
B30B-PNDZS
B32B-PNDZS
B34B-PNDZS
B36B-PNDZS
B38B-PNDZS
B40B-PNDZS
Dimensions (mm)
A
6.0
8.0
10.0
12.0
14.0
16.0
18.0
20.0
22.0
24.0
26.0
28.0
30.0
32.0
34.0
36.0
38.0
B
10.0
12.0
14.0
16.0
18.0
20.0
22.0
24.0
26.0
28.0
30.0
32.0
34.0
36.0
38.0
40.0
42.0
Q'ty / box
736
608
512
448
416
352
320
288
288
256
224
224
192
192
192
160
160
B
10.7
1.2
□0.5
2
1.45
A
5
1.55
3.2
9.9
Material and Finish
Post: Copper alloy, copper-undercoated, tin-plated (reflow treatment)
Wafer: Glass-filled PA 66, UL94V-0, ivory
RoHS compliance
This product displays (LF)(SN) on a label.
<For reference>
As the color identification,
the following alphabet shall be put in the underlined part.
For availability, delivery and minimum order quantity, contact JST.
ex.
B28B-PNDZS-1-
Z…ivory K…black R…red E…blue M…green
N…brown PK…pink D…orange
Retainer
24 circuits
34 circuits
Circuits
24
2
Model No.
PNDS-24V-Z
PNDS-34V-Z
Material
Glass-filled PA 66, UL94V-0, ivory
Q'ty / bag
1,000
1,000
34
2
23.55
2.4
1.5
2.9
7
2.35
7.5
2
2
2.4
33.55
RoHS compliance
22
32
