SO Series Current Loop Signal Isolated IC
4-20mA Current Loop Isolator
ISO 4-20mA(0-20mA) Analog Signal Isolator
Features
●4-20mA current input/output, high precision
(distortion <0.2%)
● High linearity in the full span(non-linearity<0.2%).
● Isolation between signal input and output: 3KV or
6KVDC
●Low impedance (volt. drop<2V), no external
instruments or power supply required.
● SIP 12Pin small size, UL94V-0 standard for flame
retardant encapsulation.
●4-20mA signal extra-wide range volt. Input
(8.5~28VDC).
● Frequency response (small signal band-width):
2KHZ (Io=20mA)
● Industrial operating temperature: - 45℃ ~ + 85℃
Applications
● 4-20mAsignal long-distance transmission in
industrial site
● PLC, DCS analog signals data acquisition and
isolation
● Ground loop elimination
● Transmission and Monitoring of signals of
instruments and meters, sensors,etc
● Analog signal data acquisition, isolation and long
distance non-distortion transmission.
● Monitor and control electrical instruments and
meters, medical equipments, isolated safety bar.
● Isolated safety bar in rail transit DC high voltage
monitoring
Generalization:
SunYuan
SIP12 Pin current loop isolated module: ISO 4-20mA module is a kind of single-chip two-wire
isolated interface IC chip. Inside the IC, there are current signal modulation circuit, magnetoelectric isolation
transform circuit and signal reduction demodulation circuit,etc. The low input equivalent resistance makes the IC
module achieve wide range input voltage (8.5~28VDC) to realize the long-distance, non-distortion transmission
of signals without external power supply. By adopting SMD technological structure and new isolation technology,
the modules posses the features: 3KVDC isolation between signal input and output (total isolation type), and
operates in normal in abominable industrial conditions like wide temperature, humidity and vibration.
Maximum Rated Values:
(If exceed the value below, may cause irremediable defect.)
Continuous Isolation Volt.:
Input Signal Volt. (Max.):
Operating Ambient Temp.:
Welding Temp.(<10S):
Output Short-circuit Time:
3KVDC/rms
32VDC
- 45℃ ~ + 85℃
+300℃
Main-tenability
General Technical Parameters:
Accuracy, linearity error grade ---------- 0.1, 0.2
Auxiliary power---------- No
Operating Temp. ---------- -20 ~ +70℃
Operating Humidity ---------10~90% (no condensation)
Storage Temp.---------- -20 ~ +70℃
Hysteresis error ---------- < 0.5%
Isolation ---------- signal input and output
Insulation Resistance ---------- ≥20MΩ
Withstand Voltage ---------- 3KV(60HZ/S), leak current
1mA
Impact Resistance Volt. ---------- 3KV, 1.2/50us (peak
value)
Shenzhen
Sunyuan Technology CO., Ltd.
www.szsunyuan.com
Page 1 of 3
