SHEET 1 OF 1
28.00
[1.102 in]
ACTUATOR FINISH:
STAINLESS STEEL
SWITCH FUNCTION
POS. 1
POS. 2
32.00
[1.260 in]
[.898 in]
DOT ILLUMINATION
RED
22.80
1-2
PANEL CUTOUT
MAX. PANEL THICKNESS 10mm
3-4
2.00
[.079 in]
BODY FINISH:
STAINLESS STEEL
M28x1.5
1
3
+
RED
2
4
-
21.3
[.839 in]
38.6
[1.520 in]
40.40
.50
[1.591
.020
in]
30.00
.50
[1.181
.020
in]
RED
SPDT
CONTACT CONFIGURATION
NOTE:
1. ALL DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X = ± 0.4
X.XX = ± 0.25
3. TERMINAL NOS. FOR REF. ONLY
4. FUNCTION: SPDT
5. RATING: 2A @ 48VDC
6. ILLUMINATION VOLTAGE: 24 V
7. CONTACT RESISTANCE: 50mΩ MAX. @ 1A 12VDC
8. INSULATION RESISTANCE: 1,000MΩ @ 500VDC
9. DIELECTRIC STRENGTH: 2,000VAC MIN. FOR 1 MINUTE
10. ELECTRICAL LIFE: 50,000 CYCLES
11. OPERATING TEMPERATURE: -20°C TO 55°C
12. INGRESS PROTECTION: IP65
13. SUPPLIED HARDWARE: O-RING AND HEXNUT
13. DENOTES CRITICAL PARAMETER
13. 2002/95/EC (ROHS) COMPLIANT
14. ILLUMINATION COLOR: RED (FORWARD), RED (REVERSE)
3
1
(+)
2
4
(+)
4
2
(-)
7.0
[.276 in]
13.6
[.535 in]
DOT DENOTES
LED COLOR
2.8
[.110 in]
3.0
[.118 in]
16.80
[.661 in]
23.1
[.909 in]
A
REV
21519
PCR NO
New Release
DESCRIPTION
7/16/14
DATE
rc
BY
TITLE
SCALE
PV9F2T0SS-215
1:1
DATE
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
7/16/2014
DR
rc
DWG
REV
52-PV9F2T0SS215
A
