NTE53020 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> NTE53020

NTE53020: DescriptionSilicon Bridge Rectifier, 50A; CategoryDiscrete semiconductor diode; File Size60KB，2 Pages; ManufacturerNTE; Websitehttp://www.nteinc.com; Environmental Compliance

Download Datasheet Parametric View All

NTE53020 Overview

Silicon Bridge Rectifier, 50A

NTE53020 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	NTE
package instruction	S-PUFM-D4
Reach Compliance Code	unknow
ECCN code	EAR99
Minimum breakdown voltage	1000 V
Configuration	BRIDGE, 4 ELEMENTS
Diode component materials	SILICON
Diode type	BRIDGE RECTIFIER DIODE
JESD-30 code	S-PUFM-D4
Maximum non-repetitive peak forward current	450 A
Number of components	4
Phase	1
Number of terminals	4
Maximum operating temperature	150 °C
Minimum operating temperature	-65 °C
Maximum output current	50 A
Package body material	PLASTIC/EPOXY
Package shape	SQUARE
Package form	FLANGE MOUNT
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Maximum repetitive peak reverse voltage	1000 V
surface mount	NO
Terminal form	SOLDER LUG
Terminal location	UPPER
Maximum time at peak reflow temperature	NOT SPECIFIED

Preview

Download Datasheet

View All

NTE53016 thru NTE53020

Silicon Bridge Rectifier, 50A

Features:

Diffused Junction

Low Reverse Leakage Current

Low Power Loss, High Efficiency

Electrically Isolated, Low Profile Epoxy Case for Maximum Heat Dissipation

Mounting: Through Hole with #10 Screw

Maximum Ratings and Electrical Characteristics:

= +25°C unless otherwise specified.

Single Phase, Half Wave, 60Hz, Resistive or Inductive Load, Note 1)

Maximum Recurrent Peak Reverse Voltage, V

RRM

NTE53016 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200V

NTE53018 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 600V

NTE53020 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1000V

Working Peak Reverse Voltage, V

RWM

NTE53016 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200V

NTE53018 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 600V

NTE53020 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1000V

Maximum RMS Bridge Input Voltage, V

RMS

NTE53016 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140V

NTE53018 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 420V

NTE53020 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 700V

Maximum DC Blocking Voltage, V

NTE53016 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200V

NTE53018 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 600V

NTE53020 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1000V

Maximum Average Forward Rectified Output Current (T

= +60°C), I

O(AV)

. . . . . . . . . . . . . . . . . 50A

Peak Forward Surge Current (8.3ms single half wave superimposed on rated load), I

FSM

. . . 450A

Maximum Forward Voltage Drop (Per element at 25A), V

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.1V

Maximum Reverse Current at Rated DC Blocking Voltage Per Element, I

= +25°C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50μA

= +125°C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 500μA

t Rating for Fusing (t < 8.3ms), I

t . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 800A

Typical Junction Capacitance (Note 2), C

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 400pF

Typical Thermal Resistance, Junction−to−Case (Per element, Note 3), R

thJC

. . . . . . . . . . . 1.6°C/W

RMS Isolation Voltage from Case to Leads, V

ISO

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2500V

Operating Temperature Range, T

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

−65°

to +150°C

Storage Temperature Range, T

stg

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

−65°

to +150°C

Note 1. For capacitive load, derate current by 20%.

Note 2. Measured at 1.0MHz and applied reverse voltage of 4.0VDC.

Note 3. Thermal resistance junction−to−case, mounted on a heatsink.
