SCREW TERMINAL TYPE ALUMINUM ELECTROLYTIC CAPACITORS
GX2 Series
• Conform RoHS
Useful of 8,000 hours at 105°C (Warranty of 5,000 hours at 105°C)
Features
• Developed specially for the demand of higher voltage
like Active Filters.
• Warranty life of 5000hours at 105°C with 500V
through development of electrolyte liquid and forming
technology.
Insulation plate
S-Hexagon-head bolt
Screw terminal
Vent
Anode marking
Product Specifications
Items
Specifications
Temperature range –40°C ~ +105°C
Rated voltage 400 ~ 500V.DC
Capacitance tolerance ±20% (20°C,120Hz)
0.01CV (µA) or 5mA, whichever is smaller or less
Leakage current
[C = nominal capacitance (µF), V = rated voltage (V)]
Dissipation factor Less than the value specified in the standard products table. (20˚C,120Hz)
Permissible ripple current As specified in the standard products table. (105˚C,120Hz)
After the rated voltage with specified ripple current is applied at 105°C for 5000 hours:
Capacitance tolerance: ±15% or less of the initial value
High-temperature load
Dissipation factor: 175% or less of the specified initial value
Leakage current: Specified initial value or less
φD
±1
Insulation sleeve
L
±2
Marking
Ｔ
±1
P
±1
Others
JIS C 5101-4.
(unit：mm)
Ripple current correction coefficient
Temperature (°C)
Correction coefficient
Frequency (Hz)
Correction coefficient
40
2.44
50/60
0.7
60
2.16
120
1.0
85
2.00
300
1.1
105
1.00
1k
1.3
φD
51
64
77
90
P
22.0
28.6
32.0
32.0
S
M5×10
M5×10
M5×10
M5×10
T
5.5
5.5
5.0
5.0
Cap material
Phenol
Phenol
Phenol
Phenol
≧10K
1.4
Ripple current should be under 60 Arms at M5 terminal in accordance with from
the permissible current.
Product code : (Example) GX2 type 450V 2,700µF±20%
GX2 2W 272 Y
(
D
)
D case (øD : 64mm) product
Case code(∗)
Type of bracket code
Capacitance code
Rated voltage code
Type of series
Bracket
• See page 51 for shapes and dimensions.
• Product names in the Standard Products Table correspond to the
bracket for Type Y, but Type
Ι
bracket may be used (Type of bracket
Code =
Ι
).
• If bracket are not necessary, enter "N" for the type of bracket code.
• Bracket will be delivered separately.
∗(
) Case code in parentheses : If two types of shape exist for the same rating,
enter the case code.
Standard Products Table
Rated Voltage
Code
(Surge Voltage)
(V. DC)
Capacitance
(µF)
1200
1500
1800
2200
2700
3300
3900
4700
5600
6800
8200
10000
1000
1200
1500
1800
2200
Case size
øDXL(mm)
51×75
51×96
51×115
51×130
64×96
64×115
64×130
64×155
77×115
64×170
77×130
77×155
90×131
77×195
90×171
51×75
51×96
51×115
51×130
64×96
64×115
77×96
77×115
64×170
64×195
77×171
90×157
90×171
Ripple current
tanδ
20°C,120Hz
105°C,120Hz
(Arms)
ESR(typ.)
20°C,100Hz
(m
Ω
)
Z max
20°C,10kHz
(m
Ω
)
ESL(typ.)
(nH)
21
21
21
21
22
22
22
22
24
22
24
24
24
24
24
21
21
21
21
22
22
24
24
22
22
24
24
24
Product name
GX22G122Y
GX22G152Y
GX22G182Y
GX22G222Y
GX22G272Y
GX22G332Y
GX22G392Y
GX22G472YD
GX22G472YE
GX22G562YD
GX22G562YE
GX22G682YE
GX22G682YF
GX22G822Y
GX22G103Y
GX22W102Y
GX22W122Y
GX22W152Y
GX22W182Y
GX22W222Y
GX22W272YD
GX22W272YE
GX22W332Y
GX22W392Y
GX22W472Y
GX22W562Y
GX22W682Y
GX22W822Y
400
2G
(450)
450
2W
(500)
2700
3300
3900
4700
5600
6800
8200
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
4.2
5.2
6.1
7.1
7.6
9.0
10.3
12.2
11.4
13.8
13.1
15.4
15.4
18.6
20.5
3.9
4.6
5.5
6.4
6.9
8.2
8.1
9.6
11.6
13.4
14.6
16.5
18.7
65
53
44
42
38
30
27
22
22
20
20
18
18
15
12
70
65
53
44
42
42
42
35
27
24
24
20
18
70
55
44
45
40
35
32
23
23
21
23
18
18
17
15
75
70
55
45
42
42
42
40
32
27
23
20
18
79
