500H05N204MQ4 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> capacitor> 500H05N204MQ4

500H05N204MQ4: DescriptionCAPACITOR, CERAMIC, MULTILAYER, 50V, C0G, 0.2uF, THROUGH HOLE MOUNT, RADIAL LEADED; CategoryPassive components capacitor; File Size55KB，2 Pages; ManufacturerAdvanced Monolythic Ceramics

Download Datasheet Parametric View All

500H05N204MQ4 Overview

CAPACITOR, CERAMIC, MULTILAYER, 50V, C0G, 0.2uF, THROUGH HOLE MOUNT, RADIAL LEADED

500H05N204MQ4 Parametric

Parameter Name	Attribute value
Objectid	1676607671
package instruction	,
Reach Compliance Code	unknown
ECCN code	EAR99
capacitance	0.2 µF
Capacitor type	CERAMIC CAPACITOR
dielectric materials	CERAMIC
Manufacturer's serial number	H05
Installation features	THROUGH HOLE MOUNT
multi-layer	Yes
negative tolerance	20%
Number of terminals	2
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package shape	RECTANGULAR PACKAGE
positive tolerance	20%
Rated (DC) voltage (URdc)	50 V
surface mount	NO
Temperature characteristic code	C0G
Temperature Coefficient	-/+30ppm/Cel ppm/°C
Terminal shape	WIRE

Preview

Download Datasheet

View All

www.amccaps.com

WITCH

-M

ODE

ADIAL

EADED

APACITORS

EATURES

• Rated Working Voltages from 25 to 500 VDC

• Rugged Epoxy Coating Offers Increased Protection

• Compact MLC Designs Smaller Than Film or Disc

• Hi-Rel Screened Versions Available

• Custom Sizes, Voltages, and Values Available

PPLICATIONS

• Power Supplies

• Voltage Multipliers

• Data Isolation

• Surge Protection

• Industrial Control Circuits

• Custom Applications

APACITANCE

/ V

OLTAGE

ELECTION

.300 max.

.200 max.

.200 nom.

.020 nom.

.400 max.

.200 max.

.200 nom.

.020 nom.

.500 max.

.200 max.

.400 nom.

.025 nom.

.870 max.

.600 max.

.200 max.

.790 nom.

.032 nom.

(7.62 max.)

(5.08 max.)

(5.08 nom.)

(.510 nom.)

(10.2 max.)

(5.08 max.)

(5.08 nom.)

(.510 nom.)

(12.7 max.)

(5.08 max.)

(10.2 nom.)

(.635 nom.)

(22.1 max.)

(15.2 max.)

(5.08 max.)

(20.1 nom.)

(.813 nom.)

RATED

VOLTAGE

NPO CAPACITANCE (MAX.)

VALUE

CODE

X7R CAPACITANCE (MAX.)

VALUE

CODE

H03

25 VDC

50 VDC

100 VDC

200 VDC

500 VDC

25 VDC

50 VDC

100 VDC

200 VDC

500 VDC

25 VDC

50 VDC

100 VDC

200 VDC

500 VDC

25 VDC

50 VDC

100 VDC

200 VDC

500 VDC

.070 µF

.060 µF

.050 µF

.040 µF

.020 µF

.120 µF

.100 µF

.082 µF

.050 µF

.030 µF

.240 µF

.200 µF

.180 µF

.110 µF

.070 µF

.750 µF

.620 µF

.560 µF

.360 µF

.240 µF

703

603

503

403

203

124

104

823

503

303

244

204

184

114

703

754

624

564

364

244

2.00 µF

1.60 µF

1.10 µF

.730 µF

.250 µF

5.10 µF

4.10 µF

2.70 µF

1.80 µF

.670 µF

8.70 µF

7.20 µF

4.80 µF

3.30 µF

1.10 µF

22.0 µF

17.0 µF

13.0 µF

8.00 µF

2.90 µF

205

165

115

734

254

515

415

275

185

674

875

725

485

335

115

226

176

136

805

295

H04

H05

H06

Dielectric speciﬁcations may be found on page 16.

Contact the factory for RoHS products.

If you don’t see it here, just ask.

MADE in the USA

Advanced Monolythic Ceramics, Inc., A Johanson Company 3101 Constitution Avenue, Olean, New York 14760 • (716) 372-5225 • Fax (716) 372-5467
