FEATURES
●
4:1 wide input voltage range
●
Efficiency up to 88%
6W,WIDE INPUT,ISOLATED & REGULATED
●
Operating Temperature range:
SINGLE OUTPUT, DIP PACKAGING, DC-DC CONVERTER
-40°C ~ +85°C
●
3KVDC isolation
●
Low ripple & noise
●
Short circuit protection, over voltage
protection
●
Industry standard pinout
●
Meet CISPR22/EN55022 CLASS A
RoHS
URF_P- 6WR2 Series
PART NUMBER SYSTEM
Rated Power
Package Style
Output Voltage
Input Voltage
Product Series
APPLICATION
URF_P-6WR2 series models provide 6 Watt output
power, with 4:1 wide input voltage of
9-36VDC, 18-75
VDC,output over-voltage and short-circuit protection.
And all of them can meet CISPR22/EN55022 CLASS A
without external circuit. Typical applications for these
converters are industrial, electric power, instrumentation,
telecommunication.
SELECTION GUIDE
Input Voltage(VDC)
Model
Nominal
(Range)
①
Max.
Output
Voltage
(VDC)
5
Output Current (mA)
Max.
1200
500
400
250
1200
500
400
250
Min.
60
25
20
12
60
25
20
12
Input Current
(mA)(typ.)
@Max.
Load
301
287
284
287
151
143
142
143
3
12
@No Load
Reflected
Ripple
Current
(mA,typ.)
Max.
Capacitive
Load(µF)
2200
680
680
680
2200
680
680
680
Efficiency
(%, typ.)
@Max. Load
83
87
88
87
83
87
88
87
URF2405P-6WR2
URF2412P-6WR2
URF2415P-6WR2
URF2424P-6WR2
URF4805P-6WR2
URF4812P-6WR2
URF4815P-6WR2
URF4824P-6WR2
48
(18-75)
80
24
(9-36)
40
12
15
24
5
12
15
24
20
Note:
①
Absolute maximum rating without damage on the converter, but it isn't recommended.
INTPUT SPECIFICATIONS
Item
Surge Voltage (1Sec. max.)
Start-up Voltage
No-load Input Power
Input Filter
Test Conditions
24V input
48V input
24V input
48V input
Min.
-0.7
-0.7
--
--
--
Typ.
--
--
--
--
0.2
Pi Filter
Max.
50
100
9
18
0.5
W
VDC
Unit
OUTPUT SPECIFICATIONS
Item
Output Voltage Accuracy
Line Regulation
Load Regulation
Transient Recovery Time
Transient Response Deviation
Temperature coefficient
Ripple*
Noise*
Output Over Voltage Protection
Output Short Circuit Protection
Test Conditions
5% to 100% load
Full load, Input voltage from low to high
5% to 100% load
25% load step change
100% load
20MHz Bandwidth
20MHz Bandwidth
Input voltage range
24V input
48V input
Min.
--
--
--
--
--
--
--
--
--
110
Typ.
±1
±0.2
±0.5
300
±3
--
15
65
85
120
Max.
±2
±0.5
±1
500
±5
±0.03
30
100
150
140
%Vo
Unit
%
us
%
%/°C
mVp-p
Hiccup, Continuous, automatic recovery
URF_P-6WR2
2013.07.15-A/1
Page 1 of 5
The copyright and authority for the interpretation of the products are reserved by
MORNSUN
Note:* Ripple and noise tested with "parallel cable" method. See detailed operation instructions at
DC-DC Application Notes
.
COMMON SPECIFICATIONS
Item
Isolation Voltage
Isolation Resistance
Isolation Capacitance
Switching Frequency
MTBF
Case Material
Weight
--
Test Conditions
Input-Output, Tested for 1 minute, leakage current less than 1 mA
Input-Output, Test at 500VDC
Input-Output,100KHz/0.1V
PWM mode
MIL-HDBK-217F@25℃
Min.
3000
1000
--
--
1000
Typ.
--
--
120
330
--
Max.
--
--
--
--
--
Unit
VDC
MΩ
pF
KHz
K hours
Plastic (UL94-V0)
13
--
g
ENVIRONMENTAL SPECIFICATIONS
Item
Storage Humidity
Operating Temperature
Storage Temperature
Max. Case Temperature
Lead Temperature
Cooling
Operating Temperature curve range
1.5mm from case for 10 seconds
Test Conditions
Non condensing
Power derating (above 71℃, see Figure 5)
Min.
5
-40
-55
--
--
Typ.
--
--
--
--
--
Max.
95
85
125
105
300
°C
Unit
%
Free air convection
EMC SPECIFICATIONS
CE
EMI
RE
ESD
RS
EFT
EMS
Surge
CS
Voltage dips, short and
interruptions immunity
CISPR22/EN55022 CLASS A(Recommended External Circuit)/
CLASS B(External Circuit Refer to Figure1-② or Figure 3)
CISPR22/EN55022 CLASS A(Recommended External Circuit)/
CLASS B(External Circuit Refer to Figure1-② or Figure 3)
IEC/EN61000-4-2
Contact
±4KV
IEC/EN61000-4-3
IEC/EN61000-4-4
IEC/EN61000-4-4
IEC/EN61000-4-5
IEC/EN61000-4-6
IEC/EN61000-4-29
10V/m
±2KV
±4KV
±2KV
3 Vr.m.s
0%-70%
（Recommended
Circuit Refer to Figure1-①）
（Recommended
Circuit Refer to Figure 3）
（Recommended
Circuit Refer to Figure1-① or Figure 3）
perf. Criteria B
perf. Criteria A
perf. Criteria B
perf. Criteria B
perf. Criteria B
perf. Criteria A
perf. Criteria B
EMC RECOMMENDED CIRCUIT
FUSE
V in
+
MOV
GND
TVS
C0
C1
C2
LDM
LCM
Vin
+Vo
EUT
GND
0V
LOAD
①
Recommended external circuit parameters:
Model
FUSE
MOV
LDM
TVS
C0
C1, C2
LCM
②
(Figure1)
Vin: 24V
Vin: 48V
Choose according to actual input current
S14K35
56μH
SMCJ48A
330μF/50V
2.2μF/50V
SMCJ90A
330μF/100V
2.2μF /100V
S14K60
2.2 mH, recommended to use MORNSUN’s FL2D-30-222
Note: In Figure 1,part①is EMS Recommended external circuit, part②is EMI recommended external circuit. Choose according to requirements.
EMC RECOMMENDED CIRCUIT PCB LAYOUT
(Figure 2)
The copyright and authority for the interpretation of the products are reserved by
MORNSUN
URF_P-6WR2
2013.07.15-A/1
Page 2 of 5
EMC MODULE APPLICATION CIRCUIT
FT-A/BX1D
FUSE
+Vin
+Vin
Vin
+Vo
C
-Vin
+
-Vin
EU T
+Vo
-Vo
GND
0V
Load
For nominal input voltage of 24V,C≥330μF/50V
For nominal input voltage of 48V,C≥330μF/100V
FT-A/BX1D is MORNSUN’s EFT suppresser
(Figure 3)
EMC MODULE RECOMMENDED CIRCUIT PCB LAYOUT
(Figure 4)
EMI TEST WAVEFORM (RECOMMENDED CIRCUIT FINGURE 1-②)
URF4812P-6WR2 CE（Class B, Positive line）
URF4812P-6WR2 CE（Class B, Negative line）
URF4812P-6WR2 CE（Class B, Positive line）
URF4812P-6WR2 CE（Class B, Negative line）
PRODUCT TYPICAL PERFORMANCE CURVE
Temperature Derating Graph
Opera ting Temp.(
℃
)
(Figure 5)
The copyright and authority for the interpretation of the products are reserved by
MORNSUN
URF_P-6WR2
2013.07.15-A/1
Page 3 of 5
Efficiency VS Input Voltage curve
(Full Load)
URF2405P-6WR2
100
95
90
85
80
75
70
65
60
55
50
9
12
15
18 21 24 27
Input Voltage(V)
30
33
36
Efficiency VS Output Load curve
(Vin=Vin-nominal)
URF2405P-6WR2
100
90
80
Efficiency(%)
70
60
50
40
30
20
10
0
5
10
20
30 40 50 60 70 80
Total Output Current(% )
90 100
Efficiency(%)
Efficiency VS Input Voltage curve
(Full Load)
URF4812P-6WR2
100
95
90
85
80
75
70
65
60
55
50
18 24 30 36 42 48 54 60 66 72 75
Input Voltage(V)
Efficiency VS Output Load curve
URF4812P-6WR2
(Vin=Vin-nominal)
100
90
80
Efficiency(%)
70
60
50
40
30
20
10
0
5
10
20
30 40 50 60 70 80
Total Output Current(% )
90 100
OUTLINE DIMENSIONS,RECOMMENDED FOOTPRINT & PACKAGING
The copyright and authority for the interpretation of the products are reserved by
MORNSUN
Efficiency(%)
URF_P-6WR2
2013.07.15-A/1
Page 4 of 5
TEST CONFIGURATIONS
Input Reflected-Ripple Current Test Setup
Input reflected-ripple current is measured with an inductor Lin and Capacitor Cin to simulate the source impedance.
Oscilloscope
Lin
Cin
Lin(4.7µH)
Current
Probe
DC DC
Load
Cin(220µF, ESR < 1.0Ω at 100 KHz)
DESIGN CONSIDERATIONS
1) Recommended circuit
All the URF_P-6WR2 Series have been tested according to the following recommended test circuit before leaving the factory (see Figure 6).
If you want to further decrease the input/output ripple, you can increase a capacitance-values properly or choose capacitors with low ESR, but
the total capacitance of the filter capacitor must not exceed the Max. Capacitive Load.
Cin: 10μF~47μF
Cout: 10μF
Vin
Cin
+Vo
DC
DC
Co ut
GND
(Figure 6)
0V
2) It is not recommended to increase the output power capability by connecting two or more converters in parallel.The product is not hot-
swappable
Note:
1. Min. load shouldn't be less than 5%, otherwise ripple maybe increased dramatically, If the product operates under min. load, it may not be
guaranteed to meet all specifications listed. Operation under minimum load will not damage the converter.
2. Max. Capacitive Load is tested at input voltage range and full load.
3. All specifications measured at Ta=25°C, humidity<75%, nominal input voltage and rated output load unless otherwise specified.
4. In this datasheet, all test methods are based on our corporate standards.
5. All characteristics are for listed models, and non-standard models may perform differently. Please contact our technical support for more details.
6. Please contact our technical support for any specific requirement.
7. Specifications of this product are subject to changes without prior notice.
MORNSUN Science & Technology Co.,Ltd.
Address: No. 5, Kehui St. 1, Kehui development center, Science Ave., Guangzhou Science City, Luogang district, Guangzhou,P.R.China.
Tel: 86-20-38601850
Fax:86-20-38601272
E-mail: info@mornsun.cn
Http://www.mornsun-power.com
The copyright and authority for the interpretation of the products are reserved by
MORNSUN
URF_P-6WR2
2013.07.15-A/1
Page 5 of 5
